SURFACE SOLUTIONS INDUSTRIAL APPLICATIONS 2025
INTRODUCTION 04-12 CUTTING DISCS & 13-40 GRINDING WHEELS 02 / Contents Market Solutions 04 Introducing Norton Razorstar® 05 Your safety is our priority 06 Supporting Sustainability 07 Merchandising Solutions 08 MyAbrasives 09 Passing our knowledge onto you 10 Service & Support with you in mind 11 Solutions for right angle grinder 12 Introduction 14 CUTTING DISCS & GRINDING WHEELS 16-33 for Metal Fabrication & Welding 16 for Rail 29 for Foundry 33 CUTTING DISCS 34-36 for Petrol Saws 34 for Chop Saws 35 for Stationary Machines 36 Technical Information 37 COATED ABRASIVES 41-216 Introduction 44 DISCS FOR ANGLE GRINDERS 49-80 Introduction 50 Fibre discs 53 Flap discs 60 Semi-flexible discs 68 Rapid Strip 69 Rapid Blend 71 Rapid Prep 74 Polishing discs 82 DISCS FOR MINI ANGLE GRINDERS 83-104 Speedlok discs 84 Mini Flap discs 91 Non-Woven Speedlok discs 94 Rapid Strip Speedlok discs 95 Rapid Blend Speedlok discs 96 Rapid Prep Speedlok discs 98 Speedlok Buffing & Polishing discs 100 DISCS FOR ORBITAL MACHINE 105-120 Norton Meshpower discs 106 Self-Grip & Beartex discs 108 Screenback discs 117 Plain discs 118 Beartex floor pads 120 WHEELS 121-154 Flap wheels 122 Convolutes wheels 140 Rapid Strip wheels 146 Rapid Blend unitised wheels 148 Small unitised wheels / Mounted points 151 High strength discs 152 ROLLS 155-170 Handy rolls 156 Paper & cloth rolls 160 Norton Meshpower 165 Beartex rolls 166 Rotolo Foam rolls 168 SHEETS & SPONGES 171-184 Cut sheets 172 Norton Meshpower 173 Sheets & hand pads 177 Beartex sheets &hand pads 181 Abrasive sponges 183 BELTS 185-214 File belts 186 Portable belts 193 Narrow belts 196 Rapid Prep belts 205 SPECIALTIES 215-228 Spirabands and Cones 216 Cartridge and Spiral rolls 220 Sanding stars 224 Safety advice 226
CONTENTS SUPER ABRASIVES 299-332 WIRE BRUSHES 379-421 & CARBIDE BURRS DIAMOND TOOLS 333-362 BONDED 229-298 ABRASIVES Contents / 03 Introduction 300 DIAMOND & CBN GRINDING WHEELS 304-316 for Machining round tools 306 for Round tool universal grinding 305 for Sharpening saw blades 310 for Sharpening HSS saw blades 313 for General engineering 314 Diamond lapping compounds 322 Diamond files 323 Diamond Dressers 324 Wire brushes 381 Carbide burrs 397 Norbevel Machines 408 Norbevel Cutting Heads 414 Steel wool 418 Introduction 230 PRECISION GRINDING 237-264 Introduction & Product selection 238 Straight wheels 245 Straight & tapered cups 258 Dishes 261 Cylinders 262 Segments 263 BENCH WHEELS 265-270 Why choose Norton Starline 265 Wheel Recommendation chart 267 Technical information 267 Starline bench wheels 268 Hand dresser 270 MOUNTED POINTS & WHEELS 271-280 Vitrified mounted points 274 Organic mounted points 279 DRESSING STICKS & SHARPENING STONES 281-290 Dressing sticks 282 Bench & combination oil stones 284 Abrasive & precision files 286 Abrasive slips and specialties 289 ORGANIC WHEELS & CUPS FOR SNAGGING 291-294 Snagging wheels 292 Snagging cups 292 STRAIGHT CUT-OFF WHEELS 295-298 Non-Reinforced wheels 296 Reinforced wheels 296 Introduction 334 DIAMOND BLADES 335-351 for Concrete & Reinforced Concrete 335 for Universal Building Materials 337 for Multi Materials 342 for Ceramic & Porcelain Tiles 347 for Asphalt & Abrasive Materials 351 CUP GRINDERS 352-354 for Concrete & Building Materials 352 DRILLING CORE BITS 355-362 for Concrete 355 for Universal Building Materials 358 Technical Information 360 STEP DRILLS 363-374 & CORE DRILLS Step drills 365 Core Drills 367 HOLE SAWS 375-378
METAL FABRICATION At Norton, we offer abrasive solutions for rust, weld, coating and paint removal, surface blending, finishing and polishing with excellent cut rate and life. All Norton products excel in fabrication, welding, maintenance and repair operations, keeping operating cost and downtime to a minimum. TRANSPORT From grinding and shaping to edge breaking, de-burring and finishing wings and airframes, Norton can be relied upon to deliver the highest performance. On the ground, Norton reduces operational costs and increases quality and throughput in the production of engine and body components for motorcycles, cars, trucks and trains, and for rail and track maintenance. On water, the marine industry relies on our specialist abrasives for bodywork operations. TOOLING For precision grinding and sharpening of essential implements such as shank tools, milling tools knives and saw blades, high quality Norton diamond and cBN cups and wheels are the ultimate performance solutions to deal with the most demanding materials. ENERGY The Norton Cutting-off and Grinding Disc Range is ideal for use in the manufacture and repair of upstream, midstream and downstream components, shipbuilding, oil rigs and pipelines. In addition, Norton offers complete solutions for the manufacture and maintenance of land and offshore wind turbines for OD & ID grinding, to portable cutting and finishing operations of gears and bearings, blades, vanes, seals and casings. STEEL INDUSTRY Norton abrasives for use in steel conditioning, cutting and grinding sheets, slabs, billets, bars, rounds, rolls, sheets and tubes have been designed to keep your productivity levels high and costs low. All Norton abrasives are manufactured and safety tested in accordance with the most stringent European safety standards, EN12413, ISO and oSa. MEDICAL Norton abrasives produce exceptional results, helping to manufacture quality products to the most stringent requirements of the optical, medical and metallurgical industries. Highly engineered abrasive cut-off wheels, abrasive belts, non-woven de-burring / finishing wheels & belts, bonded grinding wheels and diamond & CBN tools are used throughout the production process to produce knee & hip joints, prosthetics and medical instruments. BEARING & GEARS Norton has a full range of solutions to ensure bearings and gears are produced to the very highest standards. High performance grinding wheels with the latest innovation in bond technology; maximise efficiency and part quality. Norton profile dressers deliver a complete solution for continuous gear generation, profile grinding, bevel gear grinding, power honing. BUILDING & CONSTRUCTION Norton Clipper is a one-stop shop for all cutting, drilling, grinding and sanding jobs within the building and industrial construction markets. We can equip you with the safest and highest performing construction blades, machines and abrasives that not only help to improve your personal comfort and contribute to a greener environment improve our habitat. WOOD & COMPOSITES Whether you’re a carpenter, joiner, floor liner or furniture manufacturer or restorer, Norton has a complete offering for calibration, tool sharpening and sanding and finishing applications. Norton delivers innovative solutions across many industries where abrasives are an integral part of manufacture and repair processes. From cutting concrete, to grinding metal, to sanding composite materials, Norton abrasives addresses the needs of many markets, including: MARKET SOLUTIONS 04 / Introduction
Introduction / 05 SHARPER THAN EVER SPEEDLOK QUICK CHANGE DISCS DISCOVER MORE ON PAGE 86 HIGHER CUT RATE LONGER LIFE COOLER CUT ALSO AVAILABLE IN THE RAZORSTAR® FAMILY... FIBRE DISCS : PAGE 55 BELTS : PAGE 197 FEATURING ENGINEERED SHAPED CERAMIC GRAIN FOR: NEW
06 / Introduction DIFFERENTIATION IN THE RANGE We have one of the widest selections of abrasive products to meet every customer requirement. The range is classified into four quality-tiers (good/better/best/Innovation) to help you choose the right product for your specific application. ++++ BEST +++++ Our best tier products are top-of-the-range solutions with an impressive, measurable impact on reduced process cost. Our better tier products are the right fit when you can’t easily measure the value of a best tier product, but still have higher expectations for performance. BETTER +++ Our good tier products promise great value with great performance you’d expect from Norton, at a competitive price. GOOD INNOVATION Norton’s innovative abrasive solutions offer outstanding productivity and versatility. ABRASIVE SAFETY STARTS WITH US. YOUR SAFETY IS OUR FIRST PRIORITY SO ALL NORTON PRODUCTS ARE MANUFACTURED IN ACCORDANCE WITH THE MOST RIGOROUS EUROPEAN AND INTERNATIONAL HEALTH, SAFETY AND ENVIRONMENTAL NORMS. FEPA As a member of the Federation of European Producers of Abrasives (FEPA), we’re always up to date with the latest technical, legal and scientific regulatory frameworks, meaning we’re always one step ahead. Together with oSa, FEPA pursues the objective of supporting both the currently attained safety standards and further future developments. oSa® As a member of the Organisation for the Safety of Abrasives (oSa), we position ourselves amongst quality manufacturers with the highest safety levels and we’re proud to carry the trademark. Through a stringent monitoring and audit system year after year, we maintain our reputation as a reliably safe and responsible producer of quality abrasives. We conform to European and International standards, EN12413, EN13236 and EN13743 for bonded, diamond and coated products and ISO 9001, 14001 and OHSAS 18001 for our manufacturing sites. This is not just because it’s a legal requirement, it’s also because we care. Opt for the oSa® trademark; tested quality products of the highest safety level. YOUR SAFETY IS OUR PRIORITY
Contents / 07 To understand more and to see practical examples of the steps that we’ve taken and targets that we work to, for each of these five pillars, visit: www.nortonabrasives.com * CALCULATION METHOD: 2025 vs 2010 at isoproduction 2010/2030 vs 2017 in absolute terms ** including transport (upstream & downstream), purchases of goods and services OUR COMMITMENT TO A MORE SUSTAINABLE FUTURE Sustainability is at the core of what we do, we have clear commitments built around five pillars: TAKE ACTIONS ACROSS THE SUPPLY CHAIN • Reduction of -16% CO2 value chain emissions by 2030 (Scope 3)** • Decarbonizing our transportation • 100% of packaging recyclable, >30% of recycled or bio-sourced packaging content by 2030 LIMIT OUR ENVIRONMENTAL FOOTPRINT ENCOURAGE EMPLOYEE ENGAGEMENT • By 2030 reduce energy consumption and CO2 emissions by -33% (Scope 1 and 2)* • -50%water withdrawal and reuse by 2030 • -80% of non-valorised residues by 2030 • Reduction of waste to landfill, and reuse and recycle • Increased biodiversity and reduced pollution • Awareness and education programmes • Ambassador networks and employee ideation POSITION SUSTAINABILITY AS A DRIVER FOR GROWTH SOLUTIONS WITH END-USERS’ SAFETY, HEALTH, COMFORT AND WELLBEING AT HEART • Decarbonisation of our customers’ applications • By 2030 100% of products covered by Environmental product declaration / Life Cycle Assessment (ISO 14040) • Circular economy, recycling services, eco-innovation • Customer centricity on safety, health, comfort & wellbeing • Surface solutions to reduce vibration, noise, dust, VOC and odour • Solutions that are more respectful of the environment and the people • 100% REACH compliant Mitigating climate change means decarbonizing our economies, and here at Saint-Gobain, the goal is simple: by 2050 we must not emit any more carbon than we absorb. We must be carbon neutral, we must preserve our planets assets such as water and rare earth, and we must limit the waste that we generate. This commitment is rooted in a history of reducing our environmental impact and it is inseparable from our ambition to provide our customers with solutions to decarbonize and reduce their own environmental footprint. Our net zero ambition is also a concrete expression of our purpose, Making the world a better home! MAKING THE WORLD A BETTER HOME
08 / Introduction NORTON DISPLAY SYSTEM • Your customers can quickly and easily find the best abrasive for their job • Encourage the sale of other products through cross selling • Reduce the workload on your sales team, let the display do the selling for you • Integrated solution with optional corner fitting fits almost any space • Free standing, space saving option also available • Optional additional graphic information system tailored to you helps your customers select the right product. To find out more about the Display System, contact your Norton representative today. POINT-OF-SALE GRAPHICS Graphic templates can be adapted to suit your requirements. Attaches using magnetic strips so you can easily change the information on display. For information about tailored designs please contact your local sales representative DISPLAY KIT TYPES PK QTY NORTON CLIPPER Kit with light 1 410076979 410048416 Kit with light (UK plug) 1 410058121 410050915 Kit without light 1 410076980 410048415 ACCESSORIED PK QTY NORTON CLIPPER Header with light 1 MTO MTO Header without light 1 Shelf 1 Drill motor hooks x2 1 Euro hooks x35 1 Core Drill hook 1 DESCRIPTION PK QTY ART NO. Portable stand 1 410090016 DISPLAY KITS • The complete kit comes with all components needed to create a full display for any product range. • Kit contains: Base x1, pegboards x4, header x1, shelf x1, display bar with 5 pins x1, legs x2, pegs x35 • Accessories can be ordered separately if required. PORTABLE DISPLAY FOR CUTTING DISCS & GRINDING WHEELS • Kit contains: Unit x1, header x1, pins x22, side panels x2 • H: 1740mm x W: 380mm x D: 580mm MERCHANDISING SOLUTIONS We have a complete set of Norton branded displays to help showcase our products in all environments, plus off the shelf point-of-sale graphics that can also be tailored to customer requirements whether that’s for cutting, grinding, stock removal, or surface preparation and finishing.
Introduction / 09 ONLINE ORDERING MADE EASY MYABRASIVES FEATURES AND SERVICES INCLUDE: • Product search: search by UPC, name, category, EAN number and filter and sort search results, • Order history and reordering: see your past orders across all platforms (EDI, ABx, phone and fax). Invoices, debit/credit notes and shipping status will also be visible |in the ‘Order History’ section • Quotes: request and track quotes directly • Saved orders: save orders for future reference by putting multiple items in your cart and saving. You can also add a note to indicate future order frequency • Bulk orders: upload a CSV file directly into the system rather than having to search for each product individually • Recommended for you: shows related products you may like to order • Extra support: navigate the system with FAQs and how-to videos or contact our dedicated helpline REGISTER TODAY To register call your local customer service team and start using MyAbrasives today. MAKING ORDERING EASIER: 1. Detailed product information and specifications, including images and videos 2. Access to order confirmations, product availability and delivery lead times 3. Available from smartphones, tablets and PCs 24/7 4. Automatically creates a list of most frequently ordered products for ease of future ordering 5. Save favourite lists to make ordering quicker and easier With MyAbrasives, the ordering process is simple: Search for your product Add to basket Go to checkout
10 / Introduction YouTube Social Media Find us on YouTube: Norton Abrasives EMEA’ and click the ‘Metal Fabrication’ playlist to get answers to real life problems, select the best product for the job, and much more. Hit ‘subscribe’ to never miss a new release! Keep up to date with what’s happening at Norton via Facebook, Instagram and LinkedIn. Share your creations with us using the hashtag #Nortonabrasives, you might even get featured on one of our pages! PASSING OUR KNOWLEDGE ONTO YOU www.nortonabrasives.com With over 130 years of practical experience, Norton offers expertise, knowledge, understanding and advice and with the Norton website all of this is just a few clicks away. Whether you’re searching for a product, distributor, or looking for tips, either on a computer, phone or portable device, Norton is always by your side to offer support. Filled with articles, user guides brochures and videos, we’re always keeping you up to date with the latest news and information. At Norton, we’re always looking for new ways to bring you value. Whether that’s through our product range or additional services that increase abrasive knowledge and understanding, our aim is to help boost your abrasive sales! JOIN US! Our virtual live seminars, held by our Norton Application Engineer, Paul Gray, aim to enrich your abrasive expertise through a live demonstration of our products and processes, followed by a Q&A session where you can ‘Ask The Expert’ any questions you have related to the subject. Visit Nortonabrasives.com to find out what's on and join us for the next Live event!
Introduction / 11 TEST EXPERT The ‘Test Expert’ platform is a digial comparison tool, designed to measure efficiency improvements gained by using Norton abrasives. Our sales teams are always available to perform comparative tests with you at end-user level, quantifying savings and providing real life and real time evidence of the benefits Norton offers. We’re always at your side to provide the highest level of satisfaction. At Norton, we’re not just focused on providing great value products, but on adding value through great service. Our customers are at the heart of what we do, so we offer many support packages designed to add value to everyday processes. TRAINING Thanks to many years’ practical experience in the field, our application engineering team are able to pass on their knowledge and expertise through ‘hands-on’ training or virtual sessions designed to educate your teams and enrich their skills to help them work with your customers and find the best abrasive solutions. Whether you’re a newcomer or an experienced player in highly specialized industry, the Norton training service provides specialized and practical knowledge on how to safely use abrasive products and get the maximum performance every time. Thanks to our dedicated network of engineers, we’re able to visit you at your preferred location or alternatively, we have a number of training facilities across Europe where you’re welcome to visit. CLOSER TO YOU With manufacturing sites located in almost every European country and centrally located distribution centres with a wide shipping network, we offer a local service on a global scale, always close to you. Combine this with highly specialised sales and customer service teams, offering you support, handling enquiries and providing technical knowledge, we’re always pushing to drive business together. SERVICE & SUPPORT WITH YOU IN MIND
12 / Introduction CUTTING FINISHING AND POLISHING SURFACE PREP AND CLEANING BLENDING, REFINING AND DEBURRING GRINDING AND STOCK REMOVAL At Norton, we know a lot about abrasives. Using our technical expertise and experience gained over many years of manufacturing and selling the full range of products for the metal fabrication market, including cutting and grinding wheels, flap and fibre discs and finishing and polishing products, we can help you select the right products to support your metal fabrication customers in all applications, on any material and where any size of angle grinder is used. Our solutions empower you to navigate every stage of the application process with confidence. Whether cutting, grinding, blending, refining, cleaning, finishing or polishing, our precision-engineered abrasives ensure optimal results, enhancing productivity and profitability. SOLUTIONS FOR RIGHT ANGLE GRINDER STEP-BY-STEP PROCESSES Training and demonstration opportunities are available and held in our Centre of Excellence facilities located across Europe. For more information, visit nortonabrasives.com or contact your local sales representative.
CUTTING DISCS & GRINDING WHEELS Introduction 14 CUTTING DISCS & GRINDING WHEELS 16-33 for Metal Fabrication & Welding 16 for Rail 29 for Foundry 33 CUTTING DISCS 34-36 for Petrol Saws 34 for Chop Saws 35 for Stationary Machines 36 Technical Information 37 CUTTING DISCS & GRINDING WHEELS
14 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA PRODUCT SELECTION GUIDE CUTTING DISCS FOR ANGLE AND STRAIGHT GRINDERS Highly recommended 3 UNDERSTANDING THE PRODUCT 1 Best quality tier 2 Application material 3 Diameter x Thickness x Hole 4 Product specification 5 Maximum peripheral speed 6 Machine cutting or grinding 7 Product code 8 OSA certification 9 EN12413 The Norton range of Cutting Discs and Grinding Wheels for portable and fixed machines provide superior performance in the most stringent working environment. The product range includes state-of-the-art solutions for Cutting-off, Grinding, and Surface Finishing operations on any materials related to industrial fabrication markets. Norton, the industry’s most comprehensive Cutting-off and Grinding product line. INTRODUCTION 1 2 3 4 5 6 7 8 9 INNOVATION +++++ +++++ MATERIALS NORTON QUANTUM3 X-TREME PRO X-TREME VULCAN FOUNDRY X RAIL STARLINE 1-2-3 ALU MULTI MATERIAL Steel / construction steel 3 3 3 3 3 3 3 3 3 Low alloy 3 3 3 3 3 3 3 3 3 High alloy 3 3 3 3 Thin sheets, plates, profiles 3 3 3 3 3 3 3 Stainless steel / inox 3 3 3 3 3 3 Cast iron 3 Non ferrous 3 3 Titanium 3 3 3 Stone concrete 3 Tiles / ceramics 3 Rail hard grade 3 Rail medium grade 3 Rail soft grade 3 Glass ceramics PVC 3 ++++ ++++ ++++ +++ ++++ CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 15 www.nortonabrasives.com PRODUCT SELECTION GUIDE GRINDING WHEELS FOR ANGLE GRINDERS Highly recommended 3 MATERIALS NORTON QUANTUM3 X-TREME VULCAN FOUNDRY X STARLINE 1-2-3 ALU Steel / construction steel 3 3 3 3 3 3 Low alloy 3 3 3 3 3 3 High alloy 3 3 Thin sheets, plates, profiles 3 3 3 3 Stainless steel / inox 3 3 3 3 Cast iron 3 Non ferrous 3 Titanium 3 3 3 Stone concrete 3 Tiles / ceramics 3 Glass ceramics PVC 3 INNOVATION +++++ +++ ++++ ++++ OPERATOR COMFORT... Reduced hand fatigue from less cutting vibration. LESS GRINDING TIME… A sharper wheel for the highest metal removal & faster cutting action. LESS DOWNTIME &WASTE... From longer wheel life, using fewer wheels. 1 2 3 Norton Quantum3 CUTTING DISCS & GRINDING WHEELS
16 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA • Cutting performance taken to a new level in comfort, life and speed • For precision, speed and the most accurate cut with reduced vibration levels, helping you to cut more comfortably for longer • 1,3mm thickness is ideal for pipe cutting • Ceramic grains give this wheel it’s unique character. 1,0mm for ultimate speed and comfort. 1,6mm for absolute stability and longest life • Delivers best in class performance on Steel and Stainless Steel NORTON QUANTUM3 INNOVATION ULTRA THIN CUTTING DISCS CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING The use of abrasives in secondary steel industries is vast; from ship building and production of domestic appliances, automotive and construction components, special profiles, pipes and electrical goods to maintenance and repair of equipment, tools and machines. AIRTIGHT PACKAGING Stops atmosphere & weather elements eroding product performance DESICCANT POUCH Holds thousands of tiny pores that absorb and trap moisture in X-TEND PERFORMANCE is proven to be up to 40% better than standard packaging METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1,0x22,23* NQ 60 ZZ 25 66253371347 1,3x22,23* NQ 60 ZZ 25 66253371348 1,6x22,23* NQ 46 ZZ 25 66253371349 125 1,0x22,23* NQ 60 ZZ 25 66253371350 1,3x22,23* NQ 60 ZZ 25 66253371351 1,6x22,23* NQ 46 ZZ 25 66253371352 180 1.6x22,23 NQ 46 ZZ 25 66253371354 230 1.9x22,23 NQ 46 ZZ 25 66253371355 TYPE 42 115 0.8x22,23 NQ 60 ZZ 25 66252846642 125 0.8x22,23 NQ 60 ZZ 25 66252846643 CORDLESS COMPATIBLE * X-TEND included TUBS MADE FROM 100% RECYCLED PLASTIC. CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 17 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 125 2,0x22,23 NQ 36 Y 25 66252848856 125 2,5x22,23 NQ 24 P 25 66252845954 150 2,5x22,23 NQ 24 P 25 66252846123 230 2,5x22,23 NQ 24 P 25 66252846173 TYPE 42 125 2,5x22,23 NQ 24 P 25 66252832258 150 2,5x22,23 NQ 24 P 25 66252846125* 230 2,5x22,23 NQ 24 P 25 66252846174 • Greater wheel thickness for a more robust cut • Ceramic grain provides a fast, sharp cut time and time again • Incomparable speed in rough cutting applications on black steel • Ideal for large steel projects, shipyards, steel construction and general engineering NORTON QUANTUM3 INNOVATION CUTTING DISCS METAL INOX EXPERIENCE EXTRA SMOOTH CUTTING ACTION, THANKS TO OUR PREMIUM CERAMIC GRAIN. HOWWILL IT BENEFIT YOU? Norton Conventional Ceramic Wheel Norton Zirconia Wheel Norton Quantum3 Ceramic Wheel * Made-to-order CUTTING DISCS & GRINDING WHEELS
18 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING • Ideal for light grinding on thin walled workpieces • Combines speed and precision in grinding, deburring and bevelling • At 3mm thickness, less energy is needed to power up & use the wheel • Boost the amperage on cordless grinders due to light weight / fast cutting • Self sharpening ceramic grain technology for fast material removal resulting in less grinding time TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 3,0x22,23 NQ 30 S 10 66252846608 125 3,0x22,23 NQ 30 S 10 66252846609 NORTON QUANTUM3 INNOVATION LIGHT COMFORT GRINDING METAL INOX CUT THE CORD NOT THE POWER At 3mm thickness, less energy is needed to power up and use the wheel. Get up to 50% longer battery life from cordless grinders. CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 19 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 7,0x22,23 NQ 24 P 10 66253371361 125 7,0x22,23 NQ 24 P 10 66253371362 150 7,0x22,23 NQ 24 P 10 66253371363 125 7,0x22,23 NQ 24 N 10 66252839321 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 180 7,0x22,23 NQ 24 P 10 66253371364 230 7,0x22,23 NQ 24 P 10 66253371365 230 7,0x22,23 NQ 24 N 10 66252839322 • Self sharpening ceramic grain technology for high material removal and less grinding time • More comfortable to use with reduced hand fatigue from less cutting vibration • Longer wheel life means less downtime and waste, fewer wheels needed • Offers true savings in grinding processes • Optimised wheel for use on high frequency machines under high pressure, extra safe in all working conditions • Self sharpening ceramic grain technology for high material removal and less grinding time • More comfortable to use with reduced hand fatigue from less cutting vibration • Longer wheel life means less downtime and waste, fewer wheels needed NORTON QUANTUM3 INNOVATION GRINDING WHEELS NORTON QUANTUM3 INNOVATION HIGH FREQUENCY GRINDING WHEELS METAL INOX METAL INOX INOX INOX High Frequency machines will not reduce in revolutions when grinding pressure is increased. When using high pressure on standard or non-reinforced wheels and machines, the risk of wheel breakage is high. Also, under low pressure, non-reinforced wheels can show cracks due to fatigue within the abrasive running at high revolutions. High Frequency reinforced grinding wheels ensure safe working conditions in all circumstances. Norton Quantum3 CUTTING DISCS & GRINDING WHEELS
20 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. COMBINATION WHEELS TYPE 27 125 4,2x22,23 NQ 24 R 20 66253371357 150 4,2x22,23 NQ 24 R 20 66253371358 180 4,2x22,23 NQ 24 R 20 66253371359 230 4,2x22,23 NQ 24 R 20 66253371360 • Fast grinding formula, gets the job done quickly • Improved grinding control ensures precision and accuracy • Easy access in hard to grind areas, corners and inside tight grooves • Smoother feel, reduced fatigue and improved operator comfort • Boost the amperage on cordless grinders due to light weight / fast cutting • Ideal for pipe cutting NORTON QUANTUM3 INNOVATION COMBINATION WHEEL METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1.0x22.23 ZA60X 25 66252846978 125 1.0x22.23 ZA60X 25 66252846979 1.6x22.23 ZA46X 25 66252846980 2.0x22.23 ZA36X 25 66252846981 150 1.6x22.23 ZA46X 25 66252846982 180 1.6x22.23 ZA46X 25 66252846983 230 1.9x22.23 ZA46X 25 66252846984 X-TREME PRO HEAVY DUTY +++++ • Longest life reduces overall process cost, with more cuts per disc • Fast, straight, clean and burr free cutting reduces the need for rework • Choose Norton X-treme Pro for jobs that require that extra cutting performance METAL INOX CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 21 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1,0x22,23 A 60 V 25 66252919427 1,6x22,23 A 46 V 25 66252920339 2,0x22,23 A 36 V 25 66252920340 125 1,0x22,23 A 60 V 25 66252920341 1,3x22,23 A 60 V 25 66252837992 1,6x22,23 A 46 V 25 66252920342 2,0x22,23 A 36 V 25 66252920343 2,5x22,23 A 36 V 25 66252920350 150 1,6x22,23 A 46 V 25 66252920344 2.0x22,23 A 46 V 25 66252848817 180 1,6x22,23 A 46 V 25 66252920345 2,0x22,23 A 36 V 25 66252920346 230 1,9x22,23 A 36 V 25 66252920348 2,0x22,23 A 36 W 25 66252920360 2,5x22,23 A 36 V 25 66252920349 TYPE 42 115 2,5x22,23 A 36 V 25 66252921567 125 2,5x22,23 A 36 V 25 66252918816 230 2,5x22,23 A 36 V 25 66252918818 X-TREME +++++ • High performance aluminium oxide grain for fast and high material removal • Superior bond system holds the grain for long wheel life, resulting in less wheel erosion • Ideal for heavy industrial use on all hard steel types and alloys METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 7,0x22,23 A 24 R 10 66252918822 125 4,0x22,23 A 24 R 10 66252950672 7,0x22,23 A 24 R 10 66252918823 180 7,0x22,23 A 24 R 10 66252918824 230 7,0x22,23 A 24 R 10 66252918825 METAL INOX CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
22 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING • Dedicated for stainless steel TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1,0x22,23 A 60 T Inox 25 66252833400 1,6x22,23 A 46 T Inox 25 66252833401 125 1,0x22,23 A 60 T Inox 25 66252833402 1,6x22,23 A 46 T Inox 25 66252833403 2,5x22,23 A 30 S Inox 25 66252833409 150 1,6x22,23 A 46 T Inox 25 66252833404 180 1,6x22,23 A 46 T Inox 25 66252833405 230 1,9x22,23 A 46 T Inox 25 66252833406 2,5x22,23 A 30 S Inox 25 66252925427 TYPE 42 115 2,5x22,23 A 30 S Inox 25 66252925486 125 2,5x22,23 A 30 S Inox 25 66252925487 230 2,5x22,23 A 30 S Inox 25 66252925489 VULCAN ++++ INOX CORDLESS COMPATIBLE METAL INOX TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1,0x22,23 A 60 S 25 66252925431 1,6x22,23 A 46 S 25 66252925432 2,0x22,23 A 30 S 25 66252925437* 2,5x22,23 A 30 S 25 66252925442 3,0x22,23 A 30 S 25 66252925447 125 1,0x22,23 A 60 S 25 66252925433 1,6x22,23 A 46 S 25 66252925434 2,0x22,23 A 30 S 25 66252925438 2,5x22,23 A 30 S 25 66252925443 3,0x22,23 A 30 S 25 66252925448 150 2,0x22,23 A 30 S 25 66252925439 • Great price versus performance ratio • The general purpose range of cutting discs VULCAN ++++ CORDLESS COMPATIBLE TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6,4x22,23 A 30 S Inox 10 66252925513 125 6,4x22,23 A 30 S Inox 10 66252925514 230 6,4x22,23 A 30 S Inox 10 66252925517 INOX * Made-to-order CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 23 www.nortonabrasives.com CUTTING DISCS TYPE 41 180 1,6x22,23 A 46 S 25 66252925435 2,0x22,23 A 30 S 25 66252925440 2,5x22,23 A 30 S 25 66252925445 3,0x22,23 A 30 S 25 66252925449 230 1,9x22,23 A 46 S 25 66252925436 2,0x22,23 A 30 S 25 66252925441 2,5x22,23 A 30 S 25 66252925446 3,0x22,23 A 30 S 25 66252925450 TYPE 42 100 3,2x22,23 A 30 S 25 66252835417 115 2,5x22,23 A 30 S 25 66252925490 3,2x22,23 A 30 S 25 66252925494 125 2,5x22,23 A 30 S 25 66252925491 3,2x22,23 A 30 S 25 66252925495 150 3,2x22,23 A 30 S 25 66252925496 180 2,5x22,23 A 30 S 25 66252925492 3,2x22,23 A 30 S 25 66252925497 230 1,9x22,23 A 46 S 25 66252849388 2,5x22,23 A 30 S 25 66252925493 3,2x22,23 A 30 S 25 66252925498 ** Up to +30% performance improvement VULCAN FAST CUT ++++ METAL INOX • For use on low and medium power machines • Hard steel types TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 180 6,4x22,23 A 30 P 10 66252830805** 230 6,4x22,23 A 30 P 10 66252830807** CUTTING DISCS & GRINDING WHEELS
24 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6,4x22,23 A 30 S 10 66252925522 125 4,0x22,23 A 30 S 20 66252925519 6,4x22,23 A 30 S 10 66252925523 8,0x22,23 A 30 S 10 66252925524 150 6,4x22,23 A 30 S 10 66252925525 180 6,4x22,23 A 30 S 10 66252925526** 8,0x22,23 A 30 S 10 66252925527 230 4,0x22,23 A 30 S 20 66252925521 6,4x22,23 A 30 S 10 66252925529** METAL INOX • Great price versus performance ratio • The general purpose range of grinding wheels VULCAN ++++ CORDLESS COMPATIBLE STONE STONE CAST IRON TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 42 115 3,2x22,23 C 30 R 25 66252925500 125 3,2x22,23 C 30 R 25 66252925501 230 3,2x22,23 C 30 R 25 66252925503 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 125 6,4x22,23 C 30 R 10 66252925534 180 6,4x22,23 C 30 R 10 66252925535 230 6,4x22,23 C 30 R 10 66252925537 VULCAN COMFORT ADVANTAGE ++++ METAL INOX • Improved comfort in use • Reduced vibration • Smoother wheel wear for reduced chipping • Higher metal removal rates • Suitable for low power machines • Lower pressure needed, reduces operator fatigue • Reduces work piece burn TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6,4x22,23 A 30 P 10 66252830803 125 6,4x22,23 A 30 P 10 66252830804 ** Up to +30% performance improvement * Made-to-order CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 25 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS - ANGLE GRINDER CUTTING DISCS - LARGE DIAMETER TYPE 41 115 1,0x22,23 A 60 R 25 66252837243 1,6x22,23 A 46 R 25 66252837244 2,5x22,23 A 30 P 25 66252837249 125 1,0x22,23 A 60 R 25 66252837245 1,6x22,23 A 46 R 25 66252837246 2,5x22,23 A 30 P 25 66252837250 180 1,6x22,23 A 46 R 25 66252837247 2,5x22,23 A 30 P 25 66252837251 230 1,9x22,23 A 46 S 25 66252843278 2,0x22,23 A 36 R 25 66252837248 2,5x22,23 A 30 P 25 66252837253 TYPE 42 115 3,2x22,23 A 30 P 25 66252837275 125 3,2x22,23 A 30 P 25 66252837276 230 3,2x22,23 A 30 P 25 66252837278 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 115 6,4x22,23 A 24 Q 10 66252837263 125 6,4x22,23 A 24 Q 10 66252837264 180 6,4x22,23 A 24 Q 10 66252837268** 230 6,4x22,23 A 24 Q 10 66252837269** STARLINE +++ • Good material removal and cut rate • For general trade and general usage METAL INOX CORDLESS COMPATIBLE METAL INOX ** Up to +30% performance improvement CUTTING DISCS & GRINDING WHEELS
26 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA • Ceramic grain removes material quickly on a variety of different materials, one disc replaces many • At 3mm thick, the lightweight wheel ensures precision and accuracy during grinding • Easy access to hard to grind areas, corners and tight grooves • Smoother feel, reduced fatigue and improved operator comfort MULTI MATERIAL LIGHT COMFORT GRINDING ADAPTS TO ITS SURROUNDINGS TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 125 3,0x22,23 C 30 S 10 66252846611 • One wheel for all materials • The easy choice in general trade • No lost time due to wheel changing • Quick, comfortable and versatile MULTI MATERIAL CUTTING TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1,0x22,23 C 60 T 25 66252833258 1,6x22,23 C 46 T 25 66252828951 125 1,0x22,23 C 60 T 25 66252918924 1,6x22,23 C 46 T 25 66252828952 230 1,9x22,23 C 46 T 25 66252918925 ALU METAL INOX STONE C.TILES PVC ALU METAL INOX STONE C.TILES PVC CUT THE CORD NOT THE POWER At 3mm thickness, less energy is needed to power up and use the wheel. Get up to 50% longer battery life from cordless grinders. CORDLESS COMPATIBLE CORDLESS COMPATIBLE CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 27 www.nortonabrasives.com • Specially developed grain and bond system, designed to cut through aluminium and non-ferrous metals without clogging • Counteracts loading and wheel glazing for fast, easy and free cutting action on all non ferrous material NORTON ALU TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 115 1,0x22,23 A 60 Q 25 66252828236** 1,6x22,23 A 46 Q 25 66252828233* 125 1,0x22,23 A 60 Q 25 66252828237** 1,6x22,23 A 46 N 25 66252839270 1,6x22,23 A 46 Q 25 66252828234 2,5x22,23 A 36 Q 25 66252828227 230 1,9x22,23 A 46 N 25 66252839271 1,9x22,23 A 46 Q 25 66252828235 TYPE 42 230 3,0x22,23 A 36 Q 25 66252828231* ALU ALU CORDLESS COMPATIBLE TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 125 7,0x22,23 A 36 Q 10 66252828228 180 7,0x22,23 A 36 Q 10 66252828230* 230 7,0x22,23 A 36 Q 10 66252828232* * Made-to-order ** Up to +30% performance improvement A specialist range of discs designed for cutting and grinding Aluminium. New, upgraded wheels now provide 30% better performance with higher material removal rates, longer life and improved operator comfort. CUTTING DISCS & GRINDING WHEELS
28 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA • Cut, grind and finish with one wheel • Fine grit for a good, uniform finish when used at 15 degrees • No lost time due to wheel changing • Three layers of reinforcement for maximum safety in use 1-2-3 THE ALL IN ONE SOLUTION TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. COMBINATION WHEELS TYPE 27 115 2,2x22,23 A 46 S 25 66252829704 125 2,2x22,23 A 46 S 25 66252921592 METAL INOX CUTTING DISCS & GRINDING WHEELS FOR METAL FABRICATION & WELDING • For cutting and grinding with straight grinders or mini angle grinders • High performance grains gives long life and comfortable working • Ideal for weld removal, surface preparation, metal removal, reshaping and cutting-off rusted and corroded materials • To use with spindle on straight grinders (6mm spindle diameter) BLUE FIRE +++++ BLUE FIRE +++++ SPINDLES TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING OFF WHEELS TYPE 41 50 1,0x6,35 A 60 T 50 66252842745 2,0x6,35 A 60 T 50 66252842746 63 1,0x10 A 60 T 50 66252828195 1,0x6,35 A 60 T 50 66252828238 2,0x6,35 A 60 T 25 66252828239 76 1,0x6,35 A 60 T 50 66252828240 1,0x8,0 A 60 T 50 66252832234 1,0x10 A 60 T 50 66252828241 1,6x10 A 60 T 50 66252828242 2,0x6,35 A 60 T 25 66252828243 2,0x8,0 A 60 T 25 66252828244 2,0x10 A 60 T 25 66252828245 100 1,0x10 A 60 T 50 66252828246 1,0x16 A 60 T 50 66252828247 TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 41 50 6,0x6,35 A 24 R 10 66252828248 63 6,0x10 A 24 R 10 66252828249 76 7,0x10 A 24 R 10 66252828250 DESCRIPTION SIZE ART NO. Spindle for straight grinder 6mm 7660739614 Spindle for straight grinder 8mm 7660739616 Spindle for straight grinder 10mm 7660739615 METAL INOX METAL INOX • Spindles for use on straight grinder. With these you are guaranteed to mount your cutting-off or grinding wheel in the correct way, even if the arbor of the wheel doesn't match the original machine. CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 29 www.nortonabrasives.com CUTTING DISCS FOR RAIL The Norton Rail range provides high performance wheels for demanding operations. Rail cutting requires precision, speed and power and Norton Rail is a complete program of cutting discs suitable for any rail type (subway, tram, train) and any rail cutting machine with a clamping device (electrical and petrol). AS RAIL TRACK TECHNOLOGY CONTINUES TO MAKE MAJOR ADVANCES, NORTON IS GENERATING POWERFUL, INNOVATIVE, USER FRIENDLY SOLUTIONS TO CUT, SHAPE AND GRIND HEAVY DUTY STEELS CUTTING DISCS & GRINDING WHEELS
30 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING-OFF Arrange the workpiece so that a uniform section can be cut UNDERSTANDING THE PRODUCT TECHNICAL INFORMATION 1 Product code 2 Application material 3 Diameter x Thickness x Hole 4 Product specification 5 Maximum peripheral speed 6 Machine cutting 7 Safety pictograms 8 OSA certification 9 EN standard BF 41 FLAT CUTTING-OFF WHEELS Rail cutting-off wheels are available in 300mm for clamped rail cutting machines that operate at 80m/s. For clamped rail cutting machines that operate on 100m/s wheels are available in 350mm and 400mm. Bore dimensions of the cutting wheel can be adjusted using reduction rings that come with the original machine. 1 2 3 4 5 6 7 8 9 1. 2. 3. KEY: Oscillate the wheel, swing the machine for quickest & cleanest cut Direction of cut CUTTING DISCS FOR RAIL CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 31 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 356 4,0x22,23 NQ 24 Q 10 66252845405* 4,0x25,4 NQ 24 Q 10 66252845406 406 4,0x25,4 NQ 24 Q 10 66252846183 • Designed for comfort, built to last and 'made to bite' • Long product life reduces the number of replacement discs, reducing total abrasive cost • High speed cutting makes the overall rail repair process more efficient • The wheel does the work and less vibrations are felt through the machine reducing the risk of white finger NORTON QUANTUM3 RAIL INNOVATION NORTON QUANTUM3 RAIL DESIGNED FOR COMFORT, BUILT TO LAST, AND ‘MADE TO BITE.’ INNOVATION BOND TECHNOLOGY COMBINATION OF SHARP PREMIUM ABRASIVE GRAINS FAST CUTTING LONGER LIFE + = "The Norton Quantum3 really speeds up the cutting process - I can get through 3 cuts per wheel now, maybe even more, instead of struggling to get through one with the wheels I was using before. And it's not just that, it's much easier to use, kind of glides through the rail piece with ease. I'll definitely be switching over to Norton Quantum3" Don't just take our word for it, see what our customers have to say.... RAIL METAL * Made-to-order CUTTING DISCS & GRINDING WHEELS
32 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA RAIL ++++ RAIL METAL TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 356 4,0x25,4 ZA 24 Q Zirconia Medium 10 66252830924 406 4,0x25,4 ZA 24 Q Zirconia Medium 10 66252833665 RAIL ++++ • For a precise, straight and fast cut on rail, tram and subway track • Low vibration, consistent performance throughout wheel life • Hard, medium and soft wheels available • High quality cut to help generate a perfect weld RAIL METAL TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 350 4,0x25,4 A 24 T Hard 10 66252829588 4,0x25,4 A 24 P Soft 10 66252828620 4,0x25,4 A 24 Q Medium 10 66252833554 400 4,0x25,4 A 24 P Soft 10 66252919130 CUTTING DISCS FOR RAIL CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 33 www.nortonabrasives.com GRINDING WHEELS FOR FOUNDRY Cast iron used in foundry applications requires a specific type of cutting and grinding wheel to achieve a quick and clean cut. Norton Foundry X has been designed to remove the maximum material in the shortest time. Premium zirconia grains and heavy reinforcements ensure that Norton Foundry X performs on the most powerful machines and under pressure in the toughest circumstances. TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. GRINDING WHEELS TYPE 27 125 7,0x22,23 ZA24T LONG LIFE 10 66253371176 180 7,0x22,23 ZA20R COMFORT 10 66253370493 230 7,0x22,23 ZA24T LONG LIFE 10 66253371175 7,0x22,23 ZA20R COMFORT 10 66252842546 FOUNDRY X ++++ • New 180mm and 230mm Foundry X wheels are made with 4 layers of reinforcement to work under the highest side pressure without the risk of breakage • For use on High Frequency machines for use in enduring applications in the toughest environments METAL INOX CAST IRON High Frequency machines will not reduce in revolutions when grinding pressure is increased. When using high pressure on standard or non-reinforced wheels and machines, the risk of wheel breakage is high. Also, under low pressure, non-reinforced wheels can show cracks due to fatigue within the abrasive running at high revolutions. High Frequency reinforced grinding wheels ensure safe working conditions in all circumstances. CUTTING DISCS & GRINDING WHEELS
34 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA CUTTING DISC FOR PETROL SAWS Norton’s cutting discs for petrol saws provide high value and high performance in construction and demolition. TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 300 3,5x20,0 A 30 S 10 66252925457 3,5x22,23 A 30 S 10 66252925458 VULCAN ++++ • General purpose cutting discs for all steel petrol saw applications • Straight, fast cutting throughout long wheel life METAL CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 35 www.nortonabrasives.com TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 300 2,8x25,4 A 30 S 10 66252925460 356 3,0x25,4 A 30 S 10 66252925462 400 3,2x25,4 A 30 S 10 66252925464 3,2x32,0 A 30 S 10 66252925465* VULCAN ++++ • Clean and straight cutting on portable chop saws and fixed machines • Mechanical reinforcement for cutting metal and inox safely METAL INOX CUTTING DISCS FOR CHOP SAWS Norton’s cutting discs for chop saws provide high value and high performance in construction, fabrication, foundry and maintenance industries. * Made-to-order CUTTING DISCS & GRINDING WHEELS
36 / Cutting Discs & Grinding Wheels www.youtube.com/NortonAbrasivesEMEA TYPE DIA (mm) TxB (mm) SPEC PK QTY ART NO. CUTTING DISCS TYPE 41 400 4,5x32,0 C 30 R 10 66252925484* 300 3,0x32,0 A 30 S 10 66252925466 3,5x32,0 A 30 S 10 66252925468 356 3,5x25,4 A 30 S 10 66252925469 3,5x32,0 A 30 S 10 66252925470 3,5x32,0** A 30 S 10 66252925476* 400 3,5x25,4 A 30 S 10 66252925477* 4,0x25,4 A 30 S 10 66252925472 4,0x32,0 A 30 S 10 66252925473 VULCAN ++++ • Long wheel life with quick and free cutting • Cuts without burning, blueing or splintering the metal • Use under constant power in heavy cut-off applications • Double, full external mechanical reinforcement for excellent safety and stability METAL CUTTING DISCS FOR STATIONARY MACHINES Norton’s cutting discs for stationary machines provide high value and high performance in construction, fabrication and foundry industries. STONE CAST IRON ** Max Operating Speed 100m/s * Made-to-order CUTTING DISCS & GRINDING WHEELS
Cutting Discs & Grinding Wheels / 37 www.nortonabrasives.com TECHNICAL INFORMATION SHAPE SPECIFICATION SYSTEM BF 27 BF 41 BF 42 DEPRESSED CENTRE GRINDING WHEELS FLAT CUTTING DISCS DEPRESSED CENTRE CUTTING DISCS Available in diameters 76-230mm for hand-held machines. Available in diameters 50-400mm for hand-held machines & 250-400mm for stationary machines. Available in diameters 76-230mm for hand-held machines. Application: grinding Application: cutting-off Application: cutting-off PERSONAL PROTECTION Safety goggles, ear defenders, safety gloves, dust masks and, if conditions are severe, additional face protection. Leather aprons and safety shoes must be worn. Do not use if damaged Do not use for face grinding (ISO 7010) Do not use for wet grinding (ISO 7010) Do not use with hand-held grinding machine (ISO 7010) Refer to instruction manual/ booklet (ISO 7010) Wear ear protection (ISO 7010) Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Wear a mask (ISO 7010) Only permitted for grinding at an angle greater than 10° Only suitable for totally enclosed machines Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use Do not use for wet grinding (ISO7010) Only suitable for tot Wear eye pro Wear protectiv Refer to instruction m Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-hel Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suit ble for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-held grindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged g (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (IS 7010) Refer to instruction manual/book e (ISO 7010) 10) inding Donot usewithhand-heldgrindingmachine (ISO7010) O 7010) e greater than 10° k-up pad g (ISO7010) Do not use if damaged Do ot use for w t g indin (ISO7010) Only suitable for totally-enc os d machines Wear eye p otection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a m sk (ISO 7010) Only suitable for w t g indin Donot usewi hhand- eldgrindingmachine (ISO7010) Wear ear p otection (ISO 7010) Only permitted for grinding at an angle greater tha 10° Only t be used with a back-up pad Do not use for face grindin (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged o not use for wet gri ding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective gloves (ISO 7010) Refer to instruction manual/bookl t (ISO 7010) Wear a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-held grindingmachine (ISO7010) Wear ear protection (IS 7010) rmitted for grinding at an angle greater than 10° Only to be used with a back-up pad o not use for face grinding (ISO7010) Do not use if damaged Do not for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 7010) Wear protective lov s (ISO 7010) Refer to instruc ion ma ual/booklet (ISO 7010) Wear mask (ISO 7010) On y uitable f r wet grindin Donot usewithhand-held grindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for gr ding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only su table for totally-enclosed machines Wear eye protection (ISO 7010) Wea protect ve gloves (ISO 7010) Ref r t instruction manual/booklet (ISO 7010) Wear a mask (ISO 7010) Only suitable for we grinding Donot usewithhand-heldgrindingmachine (ISO7010) Wear ear protectio (ISO 7010) Only p mitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) Do not use if damaged Do not use for wet grinding (ISO7010) Only suitable for totally-enclosed machines Wear eye protection (ISO 701 ) Wear protective loves (ISO 7010) Refer to ins ruction manual/b oklet (ISO 7010) W ar a mask (ISO 7010) Only suitable for wet grinding Donot usewithhand-held grindingmachine (ISO7010) Wear ear protection (ISO 7010) Only permitted for grinding at an angle greater than 10° Only to be used with a back-up pad Do not use for face grinding (ISO7010) CUTTING DISCS & GRINDING WHEELS
