SURFACE SOLUTIONS AUTOMOTIVE AFTERMARKET

2 / CONTENTS CUTTING & GRINDING 10-12 Cutting discs 10 Grinding discs 11 PANEL PREPARATION & WELD GRINDING 13-14 Fibre discs, cloth discs & back-up pads 13 DEBURRING & RUST/PAINT REMOVAL 15-16 X-Treme flap discs 15 Vulcan flap discs 16 Rapid Blend discs 16 CLEANING 17-19 Rapid Strip discs 17 High strength discs 18 QUICK CHANGE DISCS FOR SMALL AREAS 20-30 Plain discs 20 Mini flap discs 23 Flexi-flap discs 23 Rapid discs range 24 High strength discs 26 E-Z Loc brushes 27 Mini grinder & Kit 28 FILE BELTS 31 HANDY ROLLS 33 STEP DRILLS, CARBIDE BURRS, WIRE BRUSHES 35-34 Step drills 35 Carbide burr kit 36 Hand brushes 36 PRE-CUT ROLLS 38 Cyclonic Multi-Air pre-cut rolls 38 CUT SHEETS & SHEETS 39-42 Cut sheets 39 Sheets 40 ROLLS 43-44 Mesh Power rolls 43 Paper rolls 44 Self-Grip rolls 44 SANDING BLOCKS, KITS & HOSES 45-46 Sanding blocks & hoses 45 Sanding block kits 46 All in one place 04 Process Solutions 05 Excellence training centres & Norton Advantage 07 INTRODUCTION 04-8 METAL WORKING 09-36 SURFACE 37-78 PREPARATION & FINISHING ROTOLO FOAM 70-71 Norton Pro Plus 70 Norton Pro 71 BEARTEX NON-WOVEN 72-74 Rotolo rolls 72 BearTex hand pads & discs 73 WATERPROOF SHEETS 75-76 Waterproof sheets 75 Norton T419, Black Ice T417 & Norton T489 75 SANDING SPONGES 77-78 Double-sided sponges 77 Soft touch sanding sponges 78 SANDING DISCS 48-60 Cyclonic Multi-Air discs & starter kit 48 Multi-Air discs 50 Mesh Power discs 53 Multi-Air back-up pads & interfaces 54 Cyclonic back-up pads 55 Norzon discs 56 Norton Pro & Pro Plus discs 56 Norton Pro & Pro Plus smart repair discs 57 Norton Pro film discs 58 Norton A293 59 Self-grip back-up pads & interfaces 59 MACHINES & ACCESSORIES 61-68 D.A. Sander, Vacuum & Accessories 61 MANUAL SANDING 37 MACHINE SANDING 47 FINISHING 69 CONTENTS

CONTENTS / 3 Masks & filter pad replacements 122 Safety Glasses 124 Overalls 126 PERSONAL 121-126 PROTECTION EQUIPMENT NORTON ICE RANGE 94-89 Film discs and sheets 94 Foam interfaces 96 Rosette discs & blocks 97 Liquid Ice detailer spray 97 ACCESSORIES 98 Cloths & Tack rags 98 Clay range 100 HEADLIGHT REPAIR KIT 101 MICROFINISHING 93-102 POLISH RANGE 105-113 G360 Super Fast Starter Kit 105 G360 Super Fast Smart Repair Kit 105 G360 System Complete Kit 105 G360 Super Fast Compound 106 G360 Super Fast Finish 106 G360 Clean & Protect 106 G3 Compounds 107 G3 Glaze Gloss enhancer 107 G3 Wax Premium Liquid Protection 108 G-Scuff Paint Preparation Paste 108 G3 Pro range 109 Polishing heads & Lambs wool 110 Backing pads & adaptors 111 Finishing cloths 113 Spurring brush 113 Degreasing wipes 113 MACHINES 114-120 G Plus Electric rotary polishing machine 114 G Plus D.A. Polisher 114 G Plus D.A. system kit 115 G Plus cordless polishing machines - tool only 116 G Plus cordless range - battery and charger 116 G Plus mini polishing machines 117 G Plus denibber tool 118 G Plus battery & charger 118 G Plus pen light 119 G Plus check light 119 MASKING TAPES 80-84 Gold & Orange tapes 80 Premium, Medium & Challenger tapes 81 Premium perforated trim tape 82 Premium foam tape 82 Standard foam tape 82 Polyethylene tape 83 Fine line tapes 83 Double-sided attachment foam tape 84 Rubber cleaning wheel 84 MASKING FILM 85-86 Plastifilm 85 Dispenser & cutter for Plastifilm 86 NORTON PAINT SYSTEM 87-92 Disposable kits 87 Refill kits 88 Reusable hard cup 88 Starter kit 88 Dispensers 88 Adapters 89 Universal paint cups, accessories and adapters 90 Mixing cups 92 Accessories 92 MASKING & PAINT 79-92 POLISHING 103-120

EVERYTHING YOU NEED ALL IN ONE PLACE From initial metal working and repair to the final detailing and polishing, Norton delivers powerful, precise, and intuitive solutions that elevate every step of the car body repair process. TOTAL SOLUTIONS SU METAL WORKING PERSONAL PROTECTION EQUIPMENT MASKING & POLISHING MICROFINISHING BONDING & SEALING

EXPLORE OUR TOTAL 360° SOLUTIONS URFACE PREPARATION & FINISHING & PAINT METALWORKING Maximise productivity from the very first repair stage. Norton delivers powerful, precisionengineered solutions for cutting, grinding, reshaping, sanding, cleaning, and removing rust or excess material from high-strength steel and modern automotive substrates - helping bodyshops work faster, reduce effort, and achieve consistent results. PRODUCT HIGHLIGHT: NORTON RAZORSTAR® QUICK CHANGE DISCS The topsize coating and extremely sharp grit enable cooler cutting, higher cut rate and better tool control, whilst delivering exceptional performance. See page 20. SURFACE PREPARATION& FINISHING Speed up preparation while maintaining total control. Whether sanding bare metal, filler, primer, basecoat, clearcoat, plastics, or composites, Norton systems are designed to reduce process time and improve finish quality. Film discs, foam-backed discs, mesh abrasives, and Cyclonic Multi-Air provide faster cutting and superior dust extraction. In final repair stages, Norton non-woven products, Rotolo Foam, and waterproof sheets ensure reliable, first-timeright results - minimising rework and maximising efficiency. PRODUCT HIGHLIGHT: NORTON ELECTRIC SANDERS & NORTON CYCLONIC® Innovative, lightweight machines deliver outstanding power in a compact, ergonomic design. When paired with the Norton Cyclonic® abrasive sanding system, they unlock superior surface preparation and finishing results. See page 48 and page 61. MASKING & PAINT Improve paint shop efficiency from preparation to application. Our performance masking tapes provide clean edges and reliable heat resistance, while specialist solutions simplify complex areas. The Norton Paint System streamlines paint preparation, mixing, and spraying - reducing cleaning time, lowering solvent consumption, and improving operator comfort and visibility. PRODUCT HIGHLIGHT: NORTON ORANGE TAPE Professional masking tape, excellent for curves, contours and irregular surfaces. Excellent adhesion to all surface types (paints, plastic films etc.) thanks to the solvent-based rubber adhesive, good stretchability. See page 80. MICROFINISHING Deliver flawless finishes with less time and effort. Norton’s abrasives, compounds, and accessories are engineered to simplify the finishing process, enabling bodyshops to achieve high-gloss, mirror-shine results quickly and consistently. PRODUCT HIGHLIGHT: NORTON PURE ICE FILM DISCS Q175 Ultra-thin film backing provides multiple benefits including excellent flexibility, conforming to contours in the car body. Water based No-Fil® stearate coating resists loading and eliminates pigtails. See page 94. POLISHING Restore perfection, faster. Farécla compounds, powered by advanced Engineered Abrasive Technology, remove scratches, sanding marks, swirls, holograms, and oxidation quickly and permanently. The result: fewer steps, reduced material usage, and a superior finish. PRODUCT HIGHLIGHT: FARÉCLA G3 PRO RANGE A comprehensive range of detailing products designed to clean, restore and finish surfaces including automotive paintwork, boat surfaces, wood lacquers and more. See page 107. BONDING & SEALING Increase reliability and confidence in every repair. OneBond adhesive and sealing solutions combine advanced formulation with practical application performance - helping bodyshops improve repair quality and reduce downtime. PRODUCT HIGHLIGHT: ONEBONDWINDSCREEN ADHESIVES Suitable for installing and replacing windscreens, back lights, quarter glass, and other automotive glazing, including sun and panoramic roofs. Visit www.onebondadhesives.com PERSONAL PROTECTIVE EQUIPMENT Protect people while maintaining productivity. Norton’s range of respiratory masks, gloves, eyewear, and protective clothing ensures safety, comfort, and compliance - supporting uninterrupted performance in the bodyshop. See page 121.

6 / INTRODUCTION PRODUCT TOOL APPLICATION METAL FILLER PRIMER PAINT CLEAR COAT CUT SHEETS SANDING BLOCK VULCAN NORTON PRO, MULTI-AIR & MULTI-AIR PLUS BEARTEX HAND PADS & THINFLEX MESHPOWER NORTON PRO PLUS HAND OR SANDING BLOCK NORTON PRO, NORTON PRO PLUS SHEETS HAND OR SANDING BLOCK BEARTEX Q775 FILM, NORTON PRO BLACK ICE WATERPROOF PAPER ROLLS HAND OR SANDING BLOCK R222 H231/G131 CYCLONIC MULTI-AIR NORTON PRO MESHPOWER SPONGES HAND SOFT-TOUCH SPONGES PRODUCT TOOL APPLICATION METAL FILLER PRIMER PAINT CLEAR COAT THIN WHEELS RIGHT ANGLE GRINDER VULCAN FIBRE DISCS NORZON, METAL FLAP DISCS VULCAN, X-TREM, FLEXI-FLAP RAPID STRIP RIGHT ANGLE OR DIE GRINDER RS, RSF, RST, TR Plus SPEEDLOK DIE GRINDER BLAZE & XTREME MINI-FLAP DISCS & SPEEDLOK DISCS, BEARTEX CLOTH DISCS ROTARY SANDER NORZON CYCLONIC MULTI-AIR DISCS ORBITAL SANDER CYCLONIC MULTI-AIR MULTI-AIR DISCS ORBITAL SANDER MULTI-AIR BLAZE MULTI-AIR NORZON MULTI-AIR MULTI-AIR MULTI-AIR SOFT-TOUCH DISCS ORBITAL SANDER MULTI-AIR MULTI-AIR MESHPOWER DISCS ORBITAL SANDER MESHPOWER SELF-GRIP† DISCS ORBITAL SANDER VULCAN NORTON ICE NORTON PRO NORTON PRO, NORTON PRO FILM PURE ICE Q175, Q775 FILM MULTI AIR CUT SHEETS ORBITAL SANDER MULTI-AIR NORZON MULTI-AIR MESHPOWER CUT SHEETS ORBITAL SANDER MESHPOWER POLISHING COMPOUNDS RIGHT ANGLE GRINDER / POLISHER LIQUID ICE SELF-GRIP DISCS ORBITAL SANDER NORTON ICE SUPERFLEXIBLE Q775 MANUAL OPERATIONS MACHINE OPERATIONS A FULL ABRASIVE OFFER

INTRODUCTION / 7 Our mobile demonstration centre allows us to meet you anywhere, for a demonstration by our technicians. This provides the opportunity to “put to the test” our Norton AdVANtage program, demonstrating the benefits of Norton’s innovative products in your own working environment. THE NORTON ADVANTAGE: WE CAN VISIT YOU ANY TIME, ANY PLACE, ANYWHERE. Our Excellence Training Centres in France, Italy, Germany and Poland, are fully equipped facilities offering professional technical locations for hands-on training based on best practices in repair shops. Our training sessions are held on a regular basis and are open to everyone! If you are interested in participating, please contact your local Norton representative to arrange a suitable date. EXCELLENCE TRAINING CENTRES It is our goal to establish a long-term relationship with our customers, with a strong emphasis on sharing our professional skills, process knowledge and providing up-to-date information regarding industry developments.

8 / INTRODUCTION

METAL WORKING / 9 www.nortonabrasives.com METAL WORKING CUTTING & GRINDING 10 Cutting discs Grinding discs PANEL PREPARATION & WELD GRINDING 13 Fibre discs DEBURRING & RUST/PAINT REMOVAL 15 X-Treme Flap discs Rapid Blend discs CLEANING 17 Rapid Strip discs High strength discs QUICK CHANGE DISCS FOR SMALL AREAS 20 Plain discs Mini flap discs Flexi-flap discs Rapid discs range High strength discs E-Z Loc brushes Mini Grinder & Kit FILE BELTS 31 HANDY ROLLS 33 STEP DRILLS, CARBIDE BURRS, WIRE BRUSHES 35 Step drills Carbide burr kit Hand brushes METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 10 / METAL WORKING METAL WORKING VULCAN CUTTING DISCS • Regarding 1,0 and 1,6mm thick discs, high performance abrasive grain yields up to 50% more cuts than standard AlOx products • Strong bond system in disc formula provides longer life, reduces workpiece burn and lowers the need for deburring • Wide range of disc sizes available for cutting and grinding using a straight grinder or angle grinder in small or hard to reach areas DIMENSIONS D x T x B (mm) MAX SPEED (m/sec) SPECIFICATION ART. NO. PK QTY 50 x 1 x 6.35 80 A 60 T-BF41 66252842745 50 50 x 2 x 6.35 80 A 60 T-BF41 66252842746 50 63 x 1 x 10 80 A 60 T-BF41 66252828195 50 63 x 1 x 6.35 80 A 60 T-BF41 66252828238 50 63 x 2 x 6.35 80 A 60 T-BF41 66252828239 25 76 x 1 x 6.35 80 A 60 T-BF41 66252828240 50 76 x 1 x 8.0 80 A 60 T-BF41 66252832234 50 76 x 1 x 10 80 A 60 T-BF41 66252828241 50 76 x 1.6 x 10 80 A 46 T-BF41 66252828242 50 76 x 2 x 10 80 A 60 T-BF41 66252828245 25 76 x 3.2 x 10 80 A 36 T - BF 41 66252849618 25 100 x 1 x 10 80 A 60 T-BF41 66252828246 50 100 x 1 x 16 80 A 60 T-BF41 66252828247 50 CUTTING & GRINDING Designed for all rough applications including: weld removal, surface preparation, metal removal, reshaping and cutting rusted and corroded materials. Norton Vulcan is the choice of the professional, cutting quickly and comfortably. METAL WORKING

METAL WORKING / 11 www.nortonabrasives.com VULCAN CUTTING DISCS DIMENSIONS D x T x B (mm) MAX SPEED (m/sec) SPECIFICATION ART. NO. PK QTY 115 x 1 x 22.23 80 A 60 T-BF41 66252833400 25 125 x 1 x 22.23 80 A 60 T-BF41 66252833402 25 125 x 1.6 x 22.23 80 A 60 T-BF41 66252833403 25 VULCAN GRINDING DISCS DIMENSIONS D x T x B (mm) MAX SPEED (m/sec) SPECIFICATION ART. NO. PK QTY 50 x 6 x 6.35 80 A 24 R-BF01 66252828248 10 63 x 6 x 10 80 A 24 R-BF01 66252828249 10 76 x 7 x 10 80 A 24 R-BF01 66252828250 10 VULCAN GRINDING DISCS DIMENSIONS D x T x B (mm) MAX SPEED (m/sec) SPECIFICATION ART. NO. PK QTY 115 x 6.4 x 22.23 80 A 30 S-BF27 66252925513 10 125 x 6.4 x 22.23 80 A 30 S-BF27 66252925514 10 TYPE 01 CORDLESS COMPATIBLE SPINDLES • Spindles for use on straight grinders • These products guarantee correct mounting of cutting discs and grinding wheels, even when the wheel arbor does not match the original machine SIZE ART. NO. PK QTY 6mm 07660739614 1 8mm 07660739616 1 10mm 07660739615 1 METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 12 / METAL WORKING METAL WORKING PNEUMATIC STRAIGHT CUT-OFF KIT • Kit designed for quick cutting in collision repair applications • Machine is delivered with a fixed safety guard and a soft grip to prevent discomfort. It is lightweight, only 0.8kg, and with low noise and low air consumption • All included Norton Vulcan wheels are 76mm to fit the 3” machine • High performance cutting disc 1.0mm, for more cuts and longer disc life • Metal/Inox 7.0mm grinding disc designed for rough applications DESCRIPTION QTY IN KIT ART. NO. Norton straight cut-off tool 1 78072756398 Norton Vulcan Inox cutting-off wheel for straight grinder 50 Norton Vulcan Metal-Inox grinding wheel for straight grinder 10 Norton standard glasses 1 Norton tool bag 1 DESCRIPTION ART NO. EXHAUST DIRECTION THROTTLE TYPE AIR CONSUMPTION INTERFACE WITH ABRASIVE WHEEL SIZE WEIGHT OF TOOL Straight pneumatic cut-off tool 66254439769 Rear Trigger 127.4 l/min @ 6.2 bar Spindle + flanges 76 mm (3”) 0.80 kg NORTON PNEUMATIC STRAIGHT CUT-OFF TOOL • Designed for collision repair applications • Fixed safety guard • Air regulation for speed control • Low noise and air consumption • Soft grip prevents discomfort • Lightweight (only 0.8kg) METAL WORKING

METAL WORKING / 13 www.nortonabrasives.com NORZON FIBRE DISCS F827 • Sharp NorZon grain provides fast cutting action and high stock removal of old paint and rust, smoothing down welding beads, light deburring and blending • The 0.8mm fibre backing and full resin bond system makes the disc strong, flexible and long lasting • The fibre discs are impregnated with active cooling agents, which prevent the workpiece from burning GRIT 115 x 22mm 125 x 22mm 180 x 22mm PK QTY 36 63642539615 63642536483 63642533063 25 50 69957360053 63642539620 63642533064 25 60 63642539616 69957360057 63642533065 25 80 63642539617 63642539622 63642533066 25 120 63642533055 63642533056 63642533068 25 PANEL PREPARATION & WELD GRINDING Weld grinding and stock removal is often required during major collision repair jobs. Norton offers a number of fibre discs and self grip discs for medium and heavy material removal from metal. MOUNTING Use with a backing pad on an angle grinder and use a tightening nut to ensure correct fixing to the machine. METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 14 / METAL WORKING METAL WORKING NORTON METAL F100 • Tough, aluminium oxide grain and additional grinding additives make F100 ideal for steel and metal alloys • The 0.8mm/0.6mm thick fibre backing provides good product life in metal removal applications GRIT 115 x 22mm 125 x 22mm 180 x 22mm PK QTY 36 66623385741 66623385768 66623385760 25 40 66623385745 66623385770 66623385752 25 50 66623385747 66623385773 66623385793 25 60 66623385748 66623385775 66623385749 25 80 66623385750 66623385776 66623385746 25 120 66623385757 66623385779 66623385739 25 MOUNTING Use with a backing pad on an angle grinder and use a tightening nut to ensure correct fixing to the machine. BACKING PADS • Suitable for F827 & F100 • M14 nut - medium hardness DIMENSIONS DENSITY ART NO. PK QTY 115 x 22mm Medium 69957382825 5 125 x 22mm Medium 69957382826 5 180 x 22mm Medium 69957382827 5 METAL WORKING

METAL WORKING / 15 www.nortonabrasives.com X-TREME R860 • 100% sharp Norzon grain for a faster cut from the very beginning • Tough polyester backing for excellent product life and more material removal with one disc • Ideal on medium to high pressure applications on carbon steel and hard metals GRIT 115 x 22mm 125 x 22mm PK QTY 40 78072726071 78072726076 10 60 78072726074 78072726077 10 80 78072726075 78072726078 10 DEBURRING & RUST/PAINT REMOVAL To help reduce processing time and lower costs, Norton flap discs are engineered for applications from light stock removal to blending, providing a high quality finish every time. MOUNTING Fits directly on angle grinders which have a tightening nut. METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 16 / METAL WORKING METAL WORKING MOUNTING Fits directly on angle grinders which have a tightening nut. VULCAN FLAP DISCS • Self-sharpening zirconia grain provides aggressive stock removal when needed and with lighter pressure, deburrs, blends and removes old paint layers and corrosion, on the periphery or interior of doors and wheel arches • Strong cotton cloth backing provides strength, flexibility and wear resistance • Optimised flap configuration and increased abrasive density makes this range ideal for all low and medium pressure applications on all metal types GRIT 115 x 22mm 125 x 22mm PK QTY 40 63642502311 63642502315 10 60 63642502312 63642502317 10 80 63642502313 63642502318 10 120 63642502314 63642502326 10 VORTEX RAPID BLEND DISCS • Combination of high performance grain and unitised construction means finishing time is reduced and part quality is increased • Thick nylon web resists loading, shedding and provides long product life • 2-in-1 action; can cut like an 8 grit flap disc and finish like a finishing disc • The undersized backing plate means the disc can be used for longer before being replaced, reducing total abrasive cost DIMS CAP CODE MAX RPM GRADE ART. NO. PK QTY 115 mm U2305 12000 VORTEX 5AM 66254429268 10 125 mm U2305 12000 VORTEX 5AM 66254496323 10 Vortex Rapid Blend MOUNTING Fits directly on angle grinders which have a tightening nut. METAL WORKING

METAL WORKING / 17 www.nortonabrasives.com BLAZE RAPID STRIP WHEELS • For use on flexible shaft grinders, straight grinders and drills • Ideal for corners and tight spaces • Cut costs by replacing some processes, multiple applications can be carried out with only one disc • Leaves the surface thorougly cleaned to ensure excellent adhesion for the next stage of the process DIMENSIONS (mm) GRADE MAX RPM ART. NO. PK QTY 100 x 13 x 12 Extra coarse 8000 66623304856 25 150 x 13 x 12 Extra coarse 8000 66261099378 15 SPINDLE MOUNTED WHEELS 100x13x6 Extra coarse 8000 66623378059 5 150x13x8 Epoxy Extra coarse 5500 66261130515 5 150x13x8 Extra coarse 5500 66623334482 5 CLEANING Make light work of removing unwanted coatings and rust from metallic components with this range of products for stripping and cleaning. This range of Rapid Strip discs have a strong open web structure that combines aggressive stock removal with a cool, conformable action that will not damage the workpiece. • Nylon fibre composition, impregnated with high performance ceramic abrasive grain provides flexibility, so the discs do not gouge the work surface, instead shaping to its contours • The open structure between the fibers prevents clogging and reduces heat build up for a great finish, first time • Cut costs by replacing some processes, multiple applications can be carried out with only one disc • Leaves the surface thorougly cleaned to ensure excellent adhesion for the next stage of the process METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 18 / METAL WORKING METAL WORKING BLAZE RAPID STRIP SPEEDLOK DISCS • For use on flexible grinders, straight grinders and drills • Ideal for rust removal from small intricate areas DIMENSIONS (mm) GRADE MAX RPM ART. NO. PK QTY 100 Extra coarse 8000 66623303921 5 BLAZE RAPID STRIP DISCS • Depressed centre disc for use on an angle grinder to work on large surfaces DIMENSIONS (mm) CAP CODE GRADE MAX RPM ART. NO. PK QTY 115 x 22 R9101 Extra coarse 12000 66623303783 10 125 x 22 R9101 Extra coarse 11000 66623303916 10 178 x 22 R9101 Extra coarse 8000 66623303920 10 BEARTEX HIGH STRENGTH DISCS • Abrasive and nylon formulation won’t tear when used on burrs and sharp edges • Smear-proof resin binders help to produce a great finish every time without the need for rework DIMENSIONS (mm) GRADE ART. NO. PK QTY 100 x 10 x 8 Coarse A 66254442046 10 100 x 10 x 8 Medium 66254429562 10 WHEEL HOLDER • Tool holders for Rapid Strip discs DIMS (mm) ART NO. PK QTY 100 x 13 x 12 07660707022 10 150 x 13 x 22 07660707023 12 TR+ HOLDER • Suitable for Rapid Strip discs • TR+ ATTACHMENT: TR+ • For 100mm Speedlock TR+ discs ART. NO. PK QTY 63642586196 1 MOUNTING Use with TR+ holder, order separately Blaze Rapid Strip METAL WORKING

METAL WORKING / 19 www.nortonabrasives.com RAPID STRIP SPEEDLOK DISCS • For use on flexible shaft grinders, straight grinders and drills • Ideal for corners and tight spaces • Good material removal for applications where less pressure is required DIMENSIONS (mm) GRADE ART. NO. PK QTY 100 Coarse 63642585751* 5 RAPID STRIP WHEELS RSF • Depressed centre disc for use on an angle grinder to work on large surfaces DIMENSIONS (mm) CAP CODE GRADE MAX RPM ART. NO. PK QTY 115 x 22 SOFT R4108 Coarse 12000 66254423036 10 R4108 Coarse 12000 66254423035 10 125 x 22 HARD R4108 Coarse 12000 63642585749 10 R4108 Coarse 12000 66261030655 10 • Nylon fibre composition of the wheel, impregnated with abrasive, gives Rapid Strip wheels flexibility so they do not gouge the work surface, instead shaping to its contours • The open structure between the fibers prevents clogging and reduces heat build up for a great finish, first time • Good material removal for applications where less pressure is required RAPID STRIP WHEELS RST • For use on flexible shaft grinders, straight grinders and drills • Ideal for corners and tight spaces • Good material removal for applications where less pressure is required DIMENSIONS (mm) GRADE ART. NO. PK QTY 100 x 13 x 6 Coarse 63642557742 10 100 x 25 x 6 Coarse 63642557745 5 150 x 13 x 8 Coarse 63642557743 10 MOUNTING Use with TR+ holder, order separately * Made-to-order METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 20 / METAL WORKING METAL WORKING NORTON RAZORSTAR® • The extremely sharp grit enables better tool control and an exceptionally high cut rate • The topsize coating, combined with the innovative shaped grain, cuts significantly cooler reducing and even eliminating burn • The heavy polyester backing supports excellent material removal while remaining flexible enough to adapt to corners and contours when used with a smaller backup pad • When used with lighter pressure, RazorStar® quick change discs produce a surface finish comparable to a 60 grit • The RazorStar® grain delivers exceptional performance on special alloys used in the aerospace industry DIA (mm) GRIT RPM ART. NO. PK QTY 50 mm 36+ 5700 - 13400 66254459347 50 75 mm 36+ 3800 - 8900 66254459349 50 QUICK CHANGE DISCS FOR SMALL AREAS Known as ‘Quick Change Discs’ for their convenience and speed during disc changeover, these mini discs have a special fastening system which enables discs to be changed quickly so no time is wasted during the application process. Designed for blending, breaking edges and removing parting lines and machine marks the discs are small in diameter, ideal for hard to reach areas and mild contours as well as small, flat surfaces. INNOVATION METAL WORKING

METAL WORKING / 21 www.nortonabrasives.com MACHINES For use on pneumatic tools and pencil grinders. MOUNTING TR: Roll-on/roll-off system using a nylon threaded male button on a pad (TR) with spindle. BLAZE X-TREME LIFE DISCS R980 • Premium ceramic grain delivers powerful cutting performance on stainless steel, inconels, chromium cobalt and titanium, even at medium pressure • Premium ceramic alumina abrasive grain provides a cool, fast cut and a long product life • Supersize layer contains active filler which promotes cool cutting and longer product life DIA (mm) GRIT ART. NO. PK QTY 50 mm 36 63642597039 50 50 63642597045 50 60 63642597050 50 80 63642597052 50 75 mm 36 63642597053 50 50 63642597057 50 60 63642597060 50 80 63642597062 50 METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 22 / METAL WORKING METAL WORKING BLAZE F980 • Patented ceramic grain delivers an outstanding cut rate, which significantly outperforms similar competitor products • The self-lubricating, advanced supersized treatment reduces heat build up, loading and glazing on stainless steel, titanium and super alloys. High performance resins offer superior grain retention, which extends the product life and keeps the disc effective for longer DIA (mm) GRIT ART. NO. PK QTY 50 mm 36 66261058704 25 50 66261058705 25 60 63642597050 50 75 mm 36 66261058708 25 50 66261058709 25 60 66261058711 25 NORZON DISCS R884 • Premium self-sharpening NorZon grain delivers fast cutting capability and high stock removal rates • The SpeedLok fixing system makes changing the discs quick and easy, reducing process time • Grinding, blending and finishing are all possible using the same tool, as NorZon discs are available in a wide range of grit sizes DIA (mm) GRADE ART. NO. PK QTY 50 mm 36 63642560882 50 50 69957389455 50 60 63642556396 50 80 63642560884 50 120 63642560885 50 75 mm 36 63642560886 50 50 69957389465 50 60 63642560887 50 80 63642560888 50 120* 66261137003 50 MACHINES For use on pneumatic tools and mini angle grinders. MOUNTING TR: Roll-on/roll-off system using a nylon threaded male button on a pad (TR) with spindle. MACHINES For use on pneumatic tools and mini angle grinders. *super size METAL WORKING

METAL WORKING / 23 www.nortonabrasives.com BLAZE MINI FLAP DISCS R980 • A mini version of the flap disc, ideal for cleaning and removing metal from flanges, panels, and finishing prior to applying primer • Extra heavy duty plastic backing supports aggressive applications where more pressure is required • Ceramic SG abrasive provides longer life than any other flap disc • Supersize layer contains active filler for cool cutting and long product life GRIT 50mm RECOMMENDED BACK UP PAD PK QTY 40 66261120104 63642556629 10 60 66261120109 10 80 66261120110 10 X-TREME MINI FLAP DISCS R860 • Ideal for cleaning, removing metal and finishing welds before applying primer • NorZon grain provides high stock removal rates with medium to high pressure • The backing system allows flexibility in blending and finishing operations and the small size can access hard to reach areas GRIT 75 mm 50 mm RECOMMENDED BACK UP PAD PK QTY 40 63642527476 66261180892 63642556629 10 60 66261180904 66261180893 10 80 63642527482 66261180894 10 MACHINES For use on pneumatic tools and mini angle grinders. MACHINES For use on pneumatic tools and mini angle grinders. MACHINES For use on pneumatic tools and mini angle grinders. X-TREME MINI-FLEXI FLAP DISCS R860 • Blend and finish small curved surfaces and contours with the flexible flap construction making light work of small welds, rust and metal • NorZon grain provides high stock removal rates with medium to high pressure • The backing system allows flexibility in blending and finishing operations and the small size can access hard to reach areas GRIT 50 mm PK QTY 40 66261180889 10 60 66261180890 10 80 66261180891 10 METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 24 / METAL WORKING METAL WORKING BLAZE RAPID STRIP • Heavily coated with super-sharp ceramic alumina grains, which ensures this disc will last twice as long as competitor products • Use for multiple operations including stripping, cleaning and finishing, provides a comparable finish to a medium surface conditioning disc • The open structure will not shed on rusted surfaces or load on soft metals GRIT GRADE ART. NO. PK QTY 50 Extra coarse 66623303912 25 75 Extra coarse 66261096557 25 RAPID STRIP • Nylon fibre composition of the wheel, impregnated with abrasive, gives Rapid Strip wheels flexibility so they do not gouge the work surface, instead shaping to its contours • The open structure between the fibres prevents clogging and reduces heat build-up for a great finish, first time • Good material removal for applications where less pressure is required DIMENSIONS (mm) GRADE ART. NO. PK QTY 50 mm Extra coarse 63642588173 10 75 mm Extra coarse 63642588175 10 MOUNTING: TR: Roll-on/roll-off system using a nylon threaded male button on a pad MOUNTING Roll-on/roll-off system using a nylon threaded male button on a pad BLAZE RAPID BLEND • Surface conditioning disc for removing abrasive scratches and surface defects, deburring, edge grinding, matting, cleaning and oxide- and rust removal • Blaze lasts up to twice as long as other ceramic discs thanks to the Norton SG grain which increase cutting power and life, with ability to remove process steps • Abrasive is distributed through the entire disc (top, bottom and sides) so all three faces can be used • Extremely versatile • Three grinding moments (Extra coarse, coarse and medium grinding) can be performed in one single grinding step • Cuts faster than standard Rapid Blend products, with minimal effect on finish DIA (mm) CAP CODE GRADE ART. NO. PK QTY 50x6 U9101 Extra coarse 66623313923 25 75x6 U9101 Extra coarse 66623313930 25 METAL WORKING

METAL WORKING / 25 www.nortonabrasives.com VORTEX RAPID BLEND OPEN • An advanced grain technology delivers a controlled cut rate, consistent finish to the workpiece, and a long product life that results in fewer disc changes • The open web structure allows the operator to blend in 3 dimensions; using the face, edge and back of the disc • Open web structure avoids loading, even on soft metals GRIT 50 mm 75 mm PK QTY Medium 66254497067 66254497068 25 MACHINES For use on pneumatic tools and mini angle grinders. MOUNTING TR: Roll-on/roll-off system using a nylon threaded male button on a pad (TR) with spindle. VORTEX RAPID PREP SCM MOUNTING: TR: Roll-on/roll-off system using a nylon threaded male button on a pad DIA (mm) CAP CODE GRADE TR PK QTY 50 mm S2103 Extra coarse 66623378336 50 S2203 Coarse 66623378340 50 S2303 Medium 66623378342 50 2403 Fine 66623378345 50 S2503 Very fine 66623378347 50 75 mm S2103 Extra coarse 66623378337 25 S2203 Coarse 66623378341 25 S2303 Medium 66623378343 25 2403 Fine 66623378346 25 S2503 Very fine 66623378348 25 • Features a thick layer of specialised Vortex grain, which extends product life and eliminates grit sequences by combining the cutting speed of a coarse grit and the finishing qualities of a fine grit • The advanced resin system and specialised Vortex grain imparts a superior smear-free finish and will not load on aluminium and other similar soft metals • Resistant to edge wear, disc lasts up to four times longer than competitor products METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 26 / METAL WORKING METAL WORKING MACHINES For use on pneumatic tools and mini angle grinders. RAPID PREP AO SCM • The open structure resists loading on softer metals so the disc can be used for longer before being changed, reducing down time and overall abrasive cost • A high content of abrasive throughout the disc means the cut rate is consistently high throughout its life • A flexible disc which conforms to contours of the part DIA CAP CODE GRADE TR PK QTY 50 mm S2108 Extra coarse 66623378355 50 S2208 Coarse 66623378359 50 S2308 Medium 66623378363 50 S2408 Fine 66623378366 50 S2508 Very fine 66623378372 50 75 mm S2108 Extra coarse 66623378356 50 S2208 Coarse 66623378360 50 S2308 Medium 66623378364 50 S2408 Fine 66623378382 50 S2508 Very fine 66623378373 50 HIGH STRENGTH BUFFING DISC • Tough, yet conformable, resists tearing on burrs and sharp edges • Follows contours and awkward profiles easily. • Premium aluminium oxide grain for aggressive blending and cleaning without smearing • Ideal for rust/oxide or coating removal, pipe ID and OD polishing, casting cleaning, highlighting (antiquing), contaminant removal, removal of handling marks, gasket removal, cleaning and blending of surface imperfections, prepping prior to soldering, removal of filling materials, cleaning angles and odd shapes • Will not stretch or shed DIA(mm) CAP CODE GRADE ART. NO. PK QTY 50 F2209 Coarse A 66254442044 20 F2303 Medium A 63642585924 50 F2506 Very Fine A 8834163987 50 75 F2209 Coarse A 66254442045 20 F2303 Medium A 8834164065 50 F2506 Very Fine A 63642585932 50 METAL WORKING

METAL WORKING / 27 www.nortonabrasives.com E-Z LOC BRUSHES • Designed for safer thick coating removal than traditional wire brushes, nylon brushes and surface conditioning discs. • Achieve a consistent finish with light pressure without damaging the workpiece. • Quick release standard TR attachment enables fast and easy brush change. DIA GRIT GRADE ART. NO. QTY 1” 36 Ultra-Coarse 79281831860 10 50 Extra-Coarse 79281831863 10 80 Coarse 79281831864 10 120 Medium 79281831865 10 220 Standard 79281831791 10 400 Fine 79281831792 10 2” 36 Ultra-Coarse 79281831861 10 50 Extra-Coarse 79281831866 10 80 Coarse 79281831867 10 120 Medium 79281831868 10 220 Standard 79281831793 10 400 Fine 79281831794 10 3” 36 Ultra-Coarse 79281831862 10 50 Extra-Coarse 79281831869 10 80 Coarse 79281831870 10 120 Medium 79281831871 10 220 Standard 79281831795 10 400 Fine 79281831796 10 METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 28 / METAL WORKING METAL WORKING DESCRIPTION ART NO. EXHAUST DIRECTION THROTTLE TYPE AIR CONSUMPTION COLLET CHUCK WEIGHT OF TOOL 50mm (2”) 22.000 MAX RPM (0,45 HP) mini angle grinder 66261177765 Rear Level 85 l/min 6mm 0,742 kg MINI ANGLE GRINDER • Model: Norton Mini Angle grinder 50mm (2”) • 22.000 MAX RPM (0,45 HP) • Designed for use with the quick-change back-up pad, SpeedLok and mini flap discs • Use with 38mm and 50mm quick change sanding discs and spindle mounted sanding specialties only. The accessories must have a rated speed greater than the speed marked on the tool Norton mini angle grinder APPLICATION TIPS: • Air tools require regular lubrication throughout the life of the tool. The air motor and bearing use compressed air to power the tool. As moisture in compressed air will rust the air motor, it must be lubricated daily. An inline oiling device is recommended. • This in an UNGUARDED tool and should NEVER be used with cut-off discs or other bonded abrasive grinding wheels. Never use any product that has a MAX RPM rating less that the RPM marked on the tool. METAL WORKING

METAL WORKING / 29 www.nortonabrasives.com MINI ANGLE GRINDER KIT • Ideal for metal car body work, the kit contains an assortment of abrasive SpeedLok discs of the most popular grades for stripping, deburring and surface blending, and the Norton mini right angle grinder • The Norton mini grinder inside the kit is compact, light weight and ideal for use on small or awkward areas. • The SpeedLok quick change system means discs can be changed quickly, reducing down time and speeding up the job DESCRIPTION QTY IN KIT ART. NO. 50mm Quick Change Holder TR 1 69957300298 50mm Vortex Rapid Prep SCM medium discs 10 50mm Blaze F980 P36 discs 25 50mm Blaze Rapid Strip extra coarse discs 10 Tool bag 1 Norton mini right angle grinder 1 MINI ANGLE GRINDER KIT STRIPPING TO BLENDING METAL INCLUDES MACHINE & ABRASIVES (50mm) • The kit contains an assortment of abrasive SpeedLok discs of the most popular grades for stripping, deburring and surface blending, and the Norton mini right angle grinder • The Norton mini grinder inside the kit is compact, light weight and ideal for use on small or awkward areas • The SpeedLok quick change system means discs can be changed quickly, reducing downtime and speeding up the job • All products come in a handy Norton tool bag, which can be reused DESCRIPTION QTY IN KIT ART. NO. Mini angle grinder Ø 50mm (2”) 22.000 MAX RPM (0.45 HP) 1 78072707340 Speedlok Blaze Ø 50mm R980 P36 5 Speedlok Blaze Ø 50mm R980 P50 5 Speedlok Blaze Ø 50mm R980 P60 5 Speedlok Blaze Ø 50mm R980 P80 5 Speedlok Blaze Ø 50mm F980 P36 5 Speedlok Blaze Ø 50mm F980 P50 5 Speedlok Blaze Ø 50mm F980 P60 5 Speedlok Blaze Ø 50mm F980 P80 5 Vortex Rapid Blend Ø 50mm 5 Rapid Strip Blaze Ø 50mm TR 5 High strength medium disc Ø 50mm 5 Pad for mini angle grinder Ø25 x 6mm - medium 1 Pad for mini angle grinder Ø50 x 6mm - hard 1 Safety glasses – standard 1 Norton bag 1 Machine to be used with 38 and 50mm discs ONLY METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 30 / METAL WORKING METAL WORKING QUICK CHANGE DISC HOLDER TR • TR ATTACHMENT: Roll-on/roll-off system using a nylon threaded male button on a pad (TR) with spindle • QUICK CHANGE HOLDER TR TR/TS DIMS Medium Hard PK QTY TR 50 mm 07660717817 63642586931 1 TR 38 mm 63642556629 1 75 mm 63642556631 66254401460 1 QUICK CHANGE DISC HOLDER TR+ • Suitable for Rapid Strip discs • ATTACHMENT: TR+ • For 100mm Speedlock TR+ discs DIMS DENSITY ART. NO PK QTY 6 mm Hard 63642586196 1 METAL WORKING

METAL WORKING / 31 www.nortonabrasives.com PNEUMATIC FILE BELT SANDER • The Norton pneumatic file belt sander makes life easier when used in hard to reach and awkward applications and areas • Use with Norton file belts for stock removal, deburring or surface preparation and defect removal on corners, contours and tight areas • Small but powerful file belt sander with 0,5 hp motor, for a mighty output • Ergonomic soft grip improves manoeuvrability and reduces operator fatigue FILE BELTS Narrow width multi-purpose belts for sanding hard to reach areas. Designed with ceramic grain to offer the best productivity and efficiency. Can be used for paint removal, cleaning, removing rust, sanding welding points and much more. PNEUMATIC FILE BELT KIT • The kit contains a wide assortment of premium ceramic and non-woven file belts, complete with pneumatic file belt sander • The ultimate solution for all applications from removal of rust and corrosion, deburring, blending and finishing panels • Machine is 10x330mm. All belts are 10x300mm to fit the machine DESCRIPTION QTY IN KIT ART. NO. File belt machine 1 78072707299 File belt R929 P60 20 File belt R929 P80 20 File belt 10x330mm BearTex: Coarse 10 File belt 10x330mm BearTex: Medium 10 File belt 10x330mm BearTex: Fine 10 Norton tool bag 1 DESCRIPTION ART NO. BELT SIZE HORSEPOWER FREE SPEED RECOMMENDED OPERATING PRESSURE TOOL WEIGHT Pneumatic file belt sander 77696091766 10x330mm 0,5 18.000rpm 6,2 bar 0,82 kg METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 32 / METAL WORKING METAL WORKING VIKING R996 • The best choice for use on stainless steel, inconels, chromium cobalt, titanium and extremely hard materials • Maximum performance for lowest overall grinding cost on the most difficult-to-grind materials • Heavy duty applications with the highest stock removal, reduced heat, loading and glazing • Advanced “supersize” grinding aid for fast and consistent cut rate with less off hand pressure required to cut WxL (mm) GRIT ART. NO. PK QTY 12 x 330 60 66261137256 50 80 66261158130 50 20 x 520 60 66261128516 10 FILE BELTS R929 • Combined SG and aluminium oxide abrasive grain provides an outstanding cut rate even at low to medium pressure and imparts an excellent surface finish • Featuring a strong polyester cloth backing and phenolic bond with active fillers for a cool and fast cut RAPID PREP SURFACE +++++ CONDITIONING FILE BELTS • Strong synthetic mesh and aluminium oxide abrasive bonded together with a smear resistant adhesive • Open construction of non-woven material for tough cutting action without clogging or loading • Ideal for removing paint, rust, adhesives, coatings and sealant corrosion in hard to access areas GRADE 10mm x 330mm PK QTY Coarse 69957360172 10 Medium 63642578004 10 Very fine 69957360176 10 GRIT 20mm x 520mm 10mm x 330mm PK QTY 12mm x 330mm PK QTY 40 66623303272 66623303110 10 60 66261029755 66261144369 10 66254488009 50 80 66623303275 66623303270 10 66254484829 50 120 66623303276 66623303271 10 METAL WORKING

METAL WORKING / 33 www.nortonabrasives.com HANDY ROLLS R222 • Aluminium oxide abrasive is sharp enough to remove material with manual pressure • Cloth backing provides flexibility for sanding round pipes, contours and curves, can also be torn easily to size • Resin bond system promotes excellent grain adhesion for applications from deburring to blending and finishing • Some grits are now made with up to 29% recycled materials, including grain, cotton cloth backing and packaging box, and are supported by an EPD certificate. GRIT 25mm x 25m 38mm x 25m 50mm x 25m PK QTY 40 63642531849 63642531828 63642531829 1 50 63642531850 63642531826 63642531827 1 60 63642531823 63642531824 63642531825 1 80 63642531820 63642531821 63642534758 1 100 63642531815 63642531817 63642531818 1 120 63642531811 63642531812 63642531814 1 150 63642531808 63642531809 63642531810 1 180 63642531805 63642531806 63642531807 1 220 63642531802 63642531803 63642531804 1 240 63642531799 63642531800 63642531801 1 280 63642536425 63642536426 1 320 63642531796 63642531797 63642531798 1 400 63642531793 63642531794 63642531795 1 600 63642560206 63642539150 63642534757 1 HANDY ROLLS Great for manual sanding operations especially on curved surfaces thanks to the flexibility of the cloth backing. Available in grades from stripping to finishing. SCAN TO VIEW EPD CERTIFICATION METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 34 / METAL WORKING METAL WORKING DISPENSER ART NO. PK QTY 69957365027 1 R822 ++++ • High-performance, self-sharpening zirconia alumina abrasive for excellent cut rate and product life • X-weight cotton backing for moderate to light pressure applications • Extremely durable for demanding applications, especially when cleaning brake callipers /-drums etc. DIM WxL (mm/m) GRIT ART NO. PK QTY 38mm x 12m 40 69957315969 1 38mm x 15m 60 69957309282 1 NON-WOVEN F2316 ++++ • Flexible 3D handpad material in roll form for for hand and machine use • Complementary to R222 and K20N handy rolls, for finishing • Premium aluminum oxide grain gives a performance boost, cleaning, blending deburring and finishing in record time • Ideal to access awkward corners and recesses DIM WxL (mm/m) GRADE CAP CODE ART NO. PK QTY 38mm x 5m F2316 Heavy Duty MED A F2316 63642531849 1 METAL WORKING

METAL WORKING / 35 www.nortonabrasives.com STEP DRILLS HSSM2-TIN • Ideal for drilling repetitive holes in metal sheets or tubes • Fast penetration, centre and drill in one operation • Works optimally on steel, cast iron, brass and plastics • Also can be used on stainless steel and bronze • Covers most common materials and hole dimensions STEP DRILLS, CARBIDE BURRS, WIRE BRUSHES Drilling, cleaning and removing rust, paint, corrosion and weld spatters. L1xD1xD2xD3 (mm) STEPS HOLE DIAMETERS (mm) MAX HOLE DEPTH (mm) PK QTY ITEM ART NO. ART NO. 65x4x12x6 9 4-5-6-7-8-9-10-11-12 3 1 78072765476 5539553847 75x4x20x8 9 4-6-8-10-12-14-16-18-20 4 1 5539553840 100x4x30x10 14 4-6-8-10-12-14-16-18-20-22-24-26-28-30 4 1 5539553845 ++++ METAL WORKING

www.youtube.com/NortonAbrasivesEMEA 36 / METAL WORKING METAL WORKING X-TREM CUT 5 +++++ CARBIDE BURR KIT • Longer life, faster stock removal and better finish than double cut carbide burrs • For use on steel, stainless steel, cast iron, nickel alloys, cobalt alloys and titanium • Ideal for fast weld removal and cleaning SHAPE D1xL1xD2xL2 (mm) ART NO. PK QTY ART NO. A 12x25x6x70 78072753479 1 78072756854 C 12x25x6x70 78072753481 1 D 12,7x10,8x6x,56 78072756783 1 F 12x25x6x70 78072753486 1 L 12x30x6x75 78072756853 1 L1xL2xL (mm) NUMBER OF ROWS PK QTY ART NO. PLASTIC HAND NORMAL STEEL STRAIGHT WIRE 0,30 mm 265x140x25 1R 12 66254405470 PLASTIC HAND STAINLESS STEEL STRAIGHT WIRE 0,30 mm 265x140x25 1R 12 66254405471 PLASTIC HAND BRASS CRIMPED WIRE 0,30 mm NON SPARK 265x140x25 1R 12 66254405473 L1xL2xL (mm) WIRE ROWS PK QTY ART NO. SPB 200x18x45 0,20 3x6R 12 66254405474 BRUSHES +++ WITH PLASTIC HANDLE • Hand brush for cleaning works in hard to reach areas • Ergonomic plastic grip for better comfort in use NON SPARK ++++ HAND BRUSH • For precision cleaning operations in environments where ‘traditional’ wire brushes may create sparks METAL WORKING

MANUAL SANDING / 37 www.nortonabrasives.com PRE-CUT ROLLS 38 Cyclonic Multi-Air pre-cut rolls CUT SHEETS & SHEETS 39 Cut sheets Sheets ROLLS 43 Mesh Power rolls Paper rolls Self-grip rolls SANDING BLOCKS, KITS & HOSES 45 Sanding blocks Hoses Sanding block kits MANUAL SANDING SURFACE PREPARATION & FINISHING MANUAL SANDING

38 / MANUAL SANDING www.youtube.com/NortonAbrasivesEMEA MANUAL SANDING STEP COLOUR APPLICATION 72mm x 12m 115mm x 12m PK QTY BOX QTY Optional Blue Stripping & levelling (Heavy Duty) 66261151791 69957305936 1 4 1 Green Stripping & filler levelling 66261151792 69957305937 1 4 2 Red Filler finishing 66261151793 69957305939 1 4 3 Salmon Primer sanding 66261151794 69957305940 1 4 CYCLONIC MULTI-AIR PRE-CUT ROLLS • As part of Cyclonic sanding system the colour coded backing represents each application step for fast and easy product selection in panel preparation, from filler levelling to primer sanding, speeding up the process • Self sharpening ceramic grain delivers superior cutting performance and longer life than other abrasive grains. Ceramic grains also cut cooler, and wear more evenly, providing consistent sanding results and a distinctly uniform scratch pattern • The No-Fil® formula prevents premature clogging of the abrasive, extending sanding time • The self-grip backing is available in two dimensions that fit all sanding blocks for a fast and easy process from start to finish PRE-CUT ROLLS Norton Cyclonic pre-cut rolls are made using the latest technology to ensure that each stage of sanding provides the best finish for the next stage of the process, minimising sanding time, increasing productivity and providing the perfect surface finish prior to painting. As part of the Norton Cyclonic Sanding System, these rolls provide the best solution for panel preparation, from filler levelling to primer sanding. MANUAL SANDING

MANUAL SANDING / 39 www.nortonabrasives.com MULTI-AIR WITH NORZON TECHNOLOGY H835 • Aggressive cutting performance for heavy applications including paint stripping and removal of body filler when sanding and flattening sharp edges, whilst imparting a consistent and uniform scratch pattern • Heavy E weight paper backing adds resistance to help this range withstand tough removal of filler on bare metal CUT SHEETS & SHEETS Manufactured to the most exacting standards, Norton’s range of sanding sheets are second to none. Each product within the portfolio is designed to deliver a high quality, consistent finish at every stage of your process. Whether you are dry sanding primer, deburring, or removing scratches, Norton has a sanding sheet for your application. Norton Multi-Air cut sheets are specially designed for dry sanding operations, to cut faster, run cooler, resist loading and last longer than conventional sandpaper. GRIT 70 x 125 mm 70 x 198 mm 70 x 420 mm 115 x 230 mm PK QTY BOX QTY 40 69957394449* 69957394363 69957394450 69957394452 50 200 60 69957394350* 69957394367 69957394358 69957394453 50 200 80 69957394355* 69957394369 69957394360 69957394454 50 200 120 69957394357* 69957394451 69957394361 69957394455 50 200 * Made-to-order MANUAL SANDING

40 / MANUAL SANDING www.youtube.com/NortonAbrasivesEMEA MANUAL SANDING GRIT 70 x 125 mm 70 x 198 mm 70 x 420 mm 115 x 230 mm PK QTY BOX QTY 80 69957394456 69957394470 69957394463 69957394479 50 200 120 69957394457 69957394472 69957394464 69957394481 50 200 150 69957394458* 69957394473 69957394465 69957394482 50 200 180 69957394459 69957394474 69957394466 69957394483 50 200 220 69957396408* 69957396410 69957396406 69957396414 50 200 240 69957394460 69957394475 69957394467 69957394484 50 200 280 69957396411* 69957396407* 69957396415* 50 200 320 69957394461 69957394477 69957394468 69957394485 50 200 400 69957394462 69957394478 69957394469 69957394486 50 200 MULTI-AIR PLUS A975 • The advanced No-Fil® coating both prevents build-up of dust and avoids premature clogging. In very fine grits, it can be used for final dry sanding before spraying, without the risk of developing runs • Patented Norton ceramic grain is blended with premium heat-treated aluminium oxide to deliver a very high cut rate that lasts up to twice as long as conventional abrasives and imparts a consistent, uniform scratch pattern • A unique fibre-reinforced latex paper backing adds to the flexibility and makes the cut sheets tear resistant in all the applications • Specifically designed for paint sanding from levelling filler to finishing primer * Made-to-order MANUAL SANDING

MANUAL SANDING / 41 www.nortonabrasives.com GRIT 70 x 125 mm 70 x 198 mm 70 x 420 mm 115 x 230 mm PK QTY BOX QTY 80 69957325770 69957325962 69957325986 69957326057 50 200 120 69957325772 69957325963 69957325987 69957326062 50 200 180 69957325773 69957325964 69957325988 69957326063 50 200 240 69957325774 69957325965 69957325990 69957326065 50 200 320 69957325775 69957325966 69957325991 69957326068 50 200 MESH POWER CERAMIC M920 • Ceramic grain provides the highest performance thanks to its micro-fracturing properties which means the abrasive stays sharper and lasts longer than the aluminium oxide version • No-Fil® technology is applied to the abrasive grain for longer product life and a consistent cut for the entire life of the product • Abrasive can be used wet or dry for the perfect results • No defined hole pattern, saves time and effort aligning holes, just apply, and go Experience powerful dust extraction with Norton MeshPower. A significant upgrade on traditional perforated discs, this solution is truly multi-functional. Designed with thousands of holes that are created by a unique mesh matrix, the MeshPower structure provides excellent dust extraction in any application. A reduction in clean up time is also a welcome benefit for any busy sander! Norton Mesh Power NORTON MULTI-AIR PAD SAVER DIMENSIONS TYPE/GRADE ART NO. PK QTY 70 x 198mm Multi-Air 69957328431 1 70 x 400mm Multi-Air 69957328432 1 MANUAL SANDING
